Edition 06/2002 Student Guide HS-50 Advanced I
10 Component Changeover Table
10
10.2.3 Docking the component changeover table
WARNING 10
Check that the placement head is outside the range of the component changeover table.
CAUTION 10
When docking the component table, ensure that the table bed is in its top end position and the
clip (item 5) is folded up.
à Carefully push the component changeover table into the placement system.
à Plug the connecting cable for the component changeover table into the socket (item 2) in the
placement system.
à Open the flap over the push-button for raising the component changeover table.
à Hold down the button (item 1) until the component table bed reaches its top end position.
à Check that the centering holes in the component table bed are exactly over the centering pins
on the placement system.
à Then fold down the clip (item 5) of the component changeover table to lower the component
table bed.
à Ensure that the centering pins engage in the centering holes in the component table bed and
that the component table bed is fully lowered.
à Close the flap over the push-button (item 1).
à Close the protective cover.
10
Student Guide HS-50 Advanced I Edition 06/2002
10 Component Changeover Table
11
10.3 Parts
Quantity Designation Item No. Comments
- 1 Component changeover 00119022-01
table (assembly)
- 1 Bellows cylinder 00337469-01 Total of 1 unit
- 1 Guide castor 00337472-01 Total of 2 unit
- 1 Fixed castor 00337471-01 Total of 2 units
- 1 Cable S-50: Changeover 00337749-02 Total of 1 unit
table assembly
- 1 Communications unit 00330037-01
- 1 Knockout spindle for No. on request
tape reel (if needed)
- 1 Edge guard 6 x 9 PVC 00129060 for cable gland
Edition 06/2002 Student Guide HS-50 Advanced I
10 Component Changeover Table
12
10.4 Overview of Mechanical Construction
Fig. 10.4.1 Overview: Layout and Exchangeable Parts of the Changeover Table HS-50
