Maintaining the empty tape cutter
Dismantling the component change-over table:
WARNING
Always couple the component change-over table to the machine before connecting or disconnect-
ing the component change-over table power cable at the machine socket.
: Move the gantry over the placement area. This will stop it outside your working area.
12
To move the gantry, take hold of the handle and push gently and carefully.
a Open the safety flap on the component table.
s Press the valve for the component change-over table lifting mechanism.
Hold it down until the component table reaches its top end position.
: Disconnect the component change-over table power cable from the placement machine.
d Pull the component change-over table out of the machine.
: Detach the waste tape chute.
: Check the cutting surfaces of the cutting blades.
The cutting blade must be turned if any irregularities are identified on the cutting surfaces. If
the cutting blade has already been turned, then it must be replaced with a new blade.
Please contact the SIPLACE Service.
: Reverse the order described above to fit the waste tape chute and component table.
: Select “Block manually” (status open) on the station computer and click on OK (for dual con-
veyor track 1 / track 2).
: Repeat these tasks at every placement machine on the line.
: Switch the placement system on again at the main switch.
: Repeat these tasks on both sides of the machines on the placement line.
06/2002 Edition Student Guide HS-50 Advanced I
12 Preventive Maintenance
66
Student Guide HS-50 Advanced I 06/2002 Edition
12 Preventive Maintenance
67
Greasing the Y axis gantries
a Turn the grease gun anti-clockwise to open.
s Pull back the piston in the grease gun.
The locking element must latch into place.
d Fill the grease gun with ISOFLEX TOPAS NCA 52 grease.
: Turn the grease gun clockwise to close.
f Release the locking element.
Spring energy moves the piston forward.
g Pull back the ball on the vent plug to vent the grease gun.
: Keep squeezing the trigger until grease starts to emerge.
The grease gun is now ready for use.
