Contents Student Guide HS-50 Advanced I
06/2002 Edition
2
20.4.5.1 Vacuum measurement and calculation at reference run . . . . . . . . . . . . . . . . . . . 28
20.4.5.2 Vacuum check after pick up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
20.4.5.3 Vacuum check before placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
20.4.5.4 Vacuum check “segment sealed” before pick up . . . . . . . . . . . . . . . . . . . . . . . . . 31
20.4.5.5 Air kiss at placement or at reject position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
20.4.6 Testing Input / Output Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
20.4.6.1 In-/Output Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
20.4.6.2 SLIO Moduls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Student Guide HS-50 Advanced I 06/2002 Edition
20 Appendix
1
20 Appendix
20.1 Overview to basic adjustments of SIPLACE HS-50
20.1.1 Belt adjustment
X-axis ended belt: 53 +1 -3 Hz
z-axis RV head endless belt: 280 +/- 10Hz
20.1.2 Collect & Place head
distance segment - dp read head: 1,5 mm
distance light barrier DOWN - sleeve: 1,3 mm
distance piston - Stern: 0,2 mm (piston on vacuum position)
air kiss pipe: 0,5 mm over segment guide
air kiss placement: 0,15 Bar
air kiss reject: 0,25 Bar
20.1.3 Adjustments of the machine
beros x/y-axes: distance 0,2 mm
bero adjustment: distance 0,3 mm
read heads x/y-axes: distance 0,4 mm
20.1.4 Pneumatic
pressure for bulk case feeder on component table:2 - 2,5 Bar
06/2002 Edition Student Guide HS-50 Advanced I
20 Appendix
2
20.2 Measuring tools and additional equipment
20.2.1 measuring tools:
E/A-Decoder 00321960-01
track signal tester new 00322510-01
Compressed Air tester 00311487-01
axis test box (cable u. adapter board) 00303430-06
belt tension measuring device new
(TRUMM, for all frequencies) 00326015-01
RC-Filter 002102858-01
20.2.2 Adjustment gauges:
Adjustment gauges set complete (contents) 00327005-01
gauge for piston (feeler gauge 0.2mm) 00325445-01
zero point gauge for Star 00326164-01
test pin for light barrier
Z-axis down 1.3mm 00326163-01
test pin for dp read head 1.4mm, 00326160-01
test pin for dp read head 1.5mm, 00326161-01
test pin for dp read head 1.6mm 00326162-01
gauge for z-axis 00331308-01
20.2.3 Lubricants:
Isoflex Topas NCA52 (piston maintenance) 00328369-01
