06/2002 Edition Student Guide HS-50 Advanced I
20 Appendix
38
Connector
SLIO Modul 1
Genral machine functions
SLIO Modul 2
genral machine functions
nozzle changer rowA
X1 S_ready Ctrl_Component counter
X2 Ctrl_ON S_Crash 1/4
X3 S_Emergency Stop Button S_Crash 2/3
X4 S_Cover S_Fan Servo OFF
X5 S_Component Table
S_Nozzles1 Left hand side
(opened)
X6 S_Key-operatedSwitch
S_Nozzles1 Right hand side
(Closed)
X7 S_ON Button Ctrl_Valve Nozzles 1
X8 S_OFF Button
S_Nozzles2 Left hand side
(opened)
X9 S_Component Flap
S_Nozzles2 Right hand side
(Closed)
X10 Spare Ctrl_Valve Nozzles 2
X11 S_Control ON
S_Nozzles1 Left hand side
(opened)
X12 Green Lamp
S_Nozzles1 Right hand side
(Closed)
X13 Fault indicator Lamp 1 Ctrl_Valve Nozzles 1
X14 Fault indicator Lamp 2
S_Nozzles2 Left hand side
(opened)
X15 RS30 / 24V DC
S_Nozzles2 Right hand side
(Closed)
X16 S_pressure sensor Ctrl_Valve Nozzles 2
X
Student Guide HS-50 Advanced I 06/2002 Edition
20 Appendix
39
Connector
SLIO Modul 3
nozzle changer row B
X1 Spare
X2 Spare
X3 Spare
X4 Spare
X5
S_Nozzles1 Left hand side
(opened)
X6
S_Nozzles1 Right hand side
(Closed)
X7 Ctrl_Valve Nozzles 1
X8
S_Nozzles2 Left hand side
(opened)
X9
S_Nozzles2 Right hand side
(Closed)
X10 Ctrl_Valve Nozzles 2
X11
S_Nozzles1 Left hand side
(opened)
X12
S_Nozzles1 Right hand side
(Closed)
X13 Ctrl_Valve Nozzles 1
X14
S_Nozzles2 Left hand side
(opened)
X15
S_Nozzles2 Right hand side
(Closed)
X16 Ctrl_Valve Nozzles 2
X
06/2002 Edition Student Guide HS-50 Advanced I
20 Appendix
40
Connector
SLIO Modul 5
Conveyor 2
SLIO Modul 6
Conveyor 1
X1
Prox, switch: lifting table 1
bottom position Prox, switch: lifting table 4 down
X2
Prox, switch: lifting table 1
Top position Prox, switch: lifting table 4 up
X3
Control signals, PCB conveyor
lifting table motors
Control signals, PCB conveyor
lifting table motors
X4
Prox, switch: lifting table 2
bottom position Prox, switch: lifting table 3 down
X5
Prox, switch: lifting table 2
Top position Prox, switch: lifting table 3 up
X6
Control signals, PCB conveyor
lifting table motors
Control signals, PCB conveyor
lifting table motors
X7
Prox, switch: stopper retracted
placement section 1
Prox, switch: stopper placement
section 4
X8
Valve stopper
Placement section 1
Prox, switch: stopper placement
section 4
X9
Prox, switch: stopper retracted
placement section 2
Prox, switch: stopper placement
section 3
X10
Valve stopper
Placement section 2
Prox, switch: stopper placement
section 3
X11
Prox, switch: add. stopper
excess length
Prox, switch: add. stopper
excess length
X12
Valve: add. stopper
excess length
Valve: add. stopper
excess length
X13
Prox, switch: position width
adjustment
Prox, switch: position width
adjustment conveyor 2
X14
Prox, switch: Ceramic substrate
centring 1
Prox, switch: Ceramic substrate
centring 4
X15
Prox, switch: Ceramic substrate
centring 2
Prox, switch: Ceramic substrate
centring 3
X16 Spare Spare
X
