06/2002 Edition Student Guide HS-50 Advanced I
2 Overview
36
2.15 Control structure
Fig. 2.15 - 1 Components of the SIPLACE LAN
2.15.1 Line Computer or Siplace Pro computer
Fig. 2.15 - 2 Line Computer
The linie computer/ Siplace Pro computer and the overlying software provides the following
functions:
- Configuration of the placement machines and lines - Creation of placement programs
- Optimization of placement sequences - Line control
- Production data aquisition - Data management
- Interface to the customer LAN
Student Guide HS-50 Advanced I 06/2002 Edition
2 Overview
37
2.15.2 Station Computer
Fig. 2.15 - 3 Station computer
2.15.3 Machine Controller
Fig. 2.15 - 4 Machine controller
The station computer is ca Pentium sys-
tem running Windows NT 4.0.
It provides the following functions:
- Provision of a multilingual graphical
user interface
- Management of the machine data
- Teaching of vision data
- Communication interface between the
line computer and the machine ontroller
The machine controller is an industrial PC
running RMOS, a realtime operating system
based on DOS.
In conjunction with the axis control cards, the
CAN cards and the vision system, it controls the
entire placement sequence-
It provides the following functions
- Control of all axis sequences
- Control of the vision system
- Monitoring of all input and output functions
- Implementation of alll operator input
06/2002 Edition Student Guide HS-50 Advanced I
2 Overview
38
2.16 Software
Line Computer Operation System UNIX SCO 5.0.5
Line Computer Software LRU 503.01
Station Computer Operating System Windows NT 4.0
Station Computer Software GUI 503.01
Machine Controller operating System RMOS 3.01
Machine Controller Software MC 503.01
ICOS Firmware 2185
Axes Firmware 4.04
Head Board (modular without Component Sensor) Firmware 05.1
Head Board (modular with Component Sensor) Firmware 6.0
Head Board Firmware 1.6
Transport 03.0a
Component Table Firmware 03.03
