ASM OIS/SIS Databases 16.0 (R18-2) / Interface Description 11/2018 Edition
15
Unique ID for Line Job
strLineJobGuid
nvarchar(36)
72
Sequence ID (internal use)
lIdSequence
bigint
8
Internal ID to mark entries referring to a "Board
Station Composite" object (for internal use
only)
lBoardCompositeId
bigint
8
Internal GUID containing a unique GUID of the
board (for internal use only)
strPCBGuid
nvarchar(256)
512
Build time of the board for the first processing
area in milliseconds
Only available for stations with station software
>= 704
lBuildTimePA1
int
4
Build time of the board for the second
processing area in milliseconds
Only available for stations with station software
>= 704
lBuildTimePA2
int
4
Reference to Panel tables entries
lIdPanel
bigint
8
Definition of ucStatus
The status of each PCB has been enhanced as of station software versions 605 and 701. As of
these versions, the status is interpreted as a bit array. The enhancement allows backward
compatibility.
1st bit:
True = PCB was aborted.
False = PCB was produced.
2nd bit:
True = PCB was produced with auto recovery.
False = PCB was produced normally without auto recovery.
3rd bit:
-
4th bit:
True = PCB is in transport through mode.
False = PCB was produced.
Definition of lSubConveyor
The lSubconveyor entry has been added to distinguish between the right and the left sub-lane if the
placement machine runs in quad lane mode. If the placement machine is not in quad lane mode
this value is always "0".
Possible values of lSubConveyor:
0:
No sub-lane
1:
Right sub-lane
2:
Left sub-lane
Definition of ucBoardSide
The ucBoardSide indicates whether the top or bottom side of the board has been processed.
Possible values of ucBoardSide:
0:
Undefined
1:
Top side
2:
Bottom side
ASM OIS/SIS Databases 16.0 (R18-2) / Interface Description 11/2018 Edition
16
4.5.1.4 EVENT Table
EVENT
OIS name
Data type
Byte
CI
I
P
Identification number of the station
(Reference to Table STATION)
lId
int
4
✓
Date/time at which this event occurred. Local station
time
dtTime
datetime
8
✓
Serial number of manufactured PCB
lBoardNumber
int
4
Conveyor belt 1 / 2
ucConveyor
tinyint
1
Processing area 1 / 2
ucProcessingArea
tinyint
1
Event number
sEvent
smallint
2
Time when the data is written. Local server time.
dtCreated
datetime
8
✓
Processing mode
ucProcessingMode
tinyint
1
Sequence ID (internal use)
lIdSequence
bigint
8
Internal ID to mark entries referring to a "Board
Station Composite" object (for internal use only)
lBoardCompositeId
bigint
8
Conveyor sub-lane
ucSubConveyor
byte
1
4.5.1.5 USEREVENT Table
USEREVENT
OIS name
Data type
Byte
CI
I
P
Identification number of the Station
(Reference to Table STATION)
lId
int
4
✓
Date/time at which this event occurred. Local station
time
dtTime
datetime
8
✓
Serial number of manufactured PCB
lBoardNumber
int
4
Conveyor belt 1 / 2
ucConveyor
tinyint
1
Processing area 1 / 2
ucProcessingArea
tinyint
1
User event number
sEvent
smallint
2
Time when the data is written. Local server time
dtCreated
datetime
8
✓
Processing mode
ucProcessingMode
tinyint
1
Sequence ID (internal use)
lIdSequence
bigint
8
Internal ID to mark entries referring to a "Board
Station Composite" object (for internal use only)
lBoardCompositeId
bigint
8
Conveyor sub-lane
ucSubConveyor
tinyint
1
ASM OIS/SIS Databases 16.0 (R18-2) / Interface Description 11/2018 Edition
17
4.5.1.6 PICKUPERROR Table
PICKUPERROR
OIS name
Data type
Byte
CI
I
P
Identification number of the station
(Reference to Table STATION)
lId
int
4
✓
Date/time at which this error occurred.
Local station time
dtTime
datetime
8
✓
Serial number of manufactured PCB
lBoardNumber
int
4
Error number
lError
int
4
Name of the component
strPartNumber
nvarchar(128)
256
Name of the component shape
strComponentShape
nvarchar(128)
256
Table/location from which the component was
retrieved
ucTable
tinyint
1
Track number
sTrack
smallint
2
Tower (MTC only, otherwise dummy)
ucTower
tinyint
1
Level (WPC or MTC only, otherwise dummy)
sLevel
smallint
2
Division
sReceptacle
smallint
2
Head identification
ucHead
tinyint
1
Segment of head
ucSegment
tinyint
1
Designation of nozzle
sNozzle
smallint
2
Time when the data is written. Local server time
dtCreated
datetime
8
✓
Error type
lType
int
4
Gantry number
lGantry
int
4
Sequence ID (internal use)
lIdSequence
bigint
8
Internal ID to mark entries referring to a "Board
Station Composite" object (for internal use only)
lBoardCompositeId
bigint
8
Unique feeder ID (available with station software
as of version 70x)
strFeederId
nvarchar(128)
256
Definition of lType (Error Types) values
0:
not defined
2:
conveyor error
3:
track error
4:
machine error
5:
general error
11:
placement error
12:
pickup error
13:
feeder error
14:
component measurement error
15:
processing component error
