ASM OIS/SIS Databases 16.0 (R18-2) / Interface Description 11/2018 Edition
24
4.5.1.18 CompBlock Table
CompBlock
OIS name
Data type
Byte
CI
I
P
Identification number of the station
(reference to STATION table)
lId
int
4
✓
Date/time at which the data record was created.
Station time
dtTime
datetime
8
✓
Serial number of manufactured PCB
lBoardNumber
int
4
Time when the data is written. Local server time
dtCreated
datetime
8
✓
Reference number of the entry.
lIdBlock
bigint
8
Unique number of the BoardComposite
lBoardCompositeId
bigint
8
4.5.1.19 CompDetail Table
CompDetail
OIS name
Data type
Byte
CI
I
P
Number of attempts to access this track
sAccessTotal
int
4
Sum of all reject attempts on this track after
Vision error messages
sRejectIdent
int
4
Sum of all reject attempts on this track after
other error messages
sRejectVacuum
int
4
Number of rejected parts because of ident error
sRejectIdent
smallint
2
Number of rejected parts because of vacuum
error
sRejectVacuum
smallint
2
Number of TrackEmpty pickup attempts
sTrackEmpty
int
4
Reference into CompBlock table
lIdBlock
bigint
8
✓
Reference into CompPosition table
lIdPosition
bigint
8
Number of successfully placed components on
this track
sPlacedComponents
int
4
Number of reject attempts on this track because
of missing components after pickup
sAbsenceAfterPick
int
4
Number of pickup attempts on this track
because of missing components before
placement
sAbsenceBefore
Placement
int
4
Number of rejects on this track because of
Coplan or material errors reported by Vision
sMaterialDefect
int
4
Number of rejects on this track because of
erroneous special procedures (dipping, gluing
etc.)
sTreatmentError
int
4
Number of rejects on this track because of an
interrupted placement process (i.e. canceled
board)
sDroppedError
int
4
Number of rejects on this track because of
pickup tolerances checked by Vision
sIdentError
int
4
Number of (incorrect) placement attempts on
this track because of gluey components
sPresenceAfter
Placement
int
4
ASM OIS/SIS Databases 16.0 (R18-2) / Interface Description 11/2018 Edition
25
Number of consecutive pickup attempts that
does not cause an track-empty error.
sPickupRetries
int
4
Version of the information source for the reject
data
sAttritionInfoVersion
int
4
Definition of sRejectVacuum
sRejectVacuum = SUM(sAbsenceAfterPick, sComponentAbsenceBeforePlacement,
sTreatmentError, sDroppedError, sComponentAbsenceAfterPlacement,
sPickupRetries)
Definition of sRejectIdent
sRejectIdent = SUM(sComponentMaterialDefect, sIdentError)
Definition of sPlacedComponents values
-1:
Undefined for all data records issued by a station with a station software version < 708
0:
No successful placement (i. e. pass-through mode, canceled board etc.)
n:
n successful placements
Definition of sAttritionInfoVersion values
0:
Reject data comes from a station software version < 708
1:
Reject data comes from astation software version >= 708
ASM OIS/SIS Databases 16.0 (R18-2) / Interface Description 11/2018 Edition
26
4.5.1.20 CompPosition Table
CompPosition
OIS name
Data type
Byte
CI
I
P
Identification number of the station
(reference to STATION table)
lId
int
4
Reference number of the entry
lIdPosition
bigint
8
Table/location from which the component was
retrieved
ucTable
tinyint
1
Track number
sTrack
smallint
2
Tower (MTC only, otherwise dummy)
ucTower
tinyint
1
Level (WPC or MTC only, otherwise dummy)
sLevel
smallint
2
Division
sReceptacle
smallint
2
Identification number of the component name
(available with station software version 701 and
higher)
lPartNumber
int
4
Identification number of the component shape
name (available with station software version
701 and higher)
lComponentShape
int
4
SIPLACE Pro number for feeder type (available
with station software version 701 and higher)
lFeederType
long
4
Time when the data is written. Local server time
dtCreated
datetime
8
Unique feeder ID
strFeederId
nvarchar(128)
256
4.5.1.21 Panel Table
Panel
OIS name
Data type
Byte
CI
I
P
Reference (from BOARD table).
Note: This reference may occur several times
since a board may have several panel groups.
lIdPanel
bigint
8
Count of produced panels
lCountProduced
int
4
Count of omitted panels
lCountOmitted
int
1
Encoding whether the panel entry is intended to
be counted as assembled PCB (based on
SIPLACE Pro setting)
CountAsAssembledPCB
tinyint
2
Name of the concerned placement list
strPlacementListName
nvarchar(256)
512
Definition of CountAsAssembledPCB values
0:
Undefined
1:
True
2:
False
