3OM-1751 1-69 1303-001 [2] Recognition Image Display Section The recognition result is displayed. [3] T eaching Result Before : Displayed are the offset values before the teaching operation. After : Displayed are the off…
3OM-1751
1-681303-001
[
] button
: Image Enlargement Mode
After changing to the image enlargement mode using the
[
] button (the shape of the pointer is changed to ),
when the image to be enlarged is touched, or the left button
of the mouse is clicked on the image, the image is enlarged
from the pointer position as the center.
When the image is to be enlarged with its position xed,
place the pointer on the center of the image before the
enlargement operation.
[
] button
: Image Reduction Mode
After changing to the image reduction mode using the
[
] button (the shape of the pointer is changed to )
when the image to be reduced is touched, or the left button
of the mouse is clicked on the image, the image is reduced
from the pointer position as the center.
When the image is to be reduced with its position xed,
place the pointer on the center of the image before the
reduction operation.
[
] button
: Image Fitting Mode (the image is displayed fully using the
recognition image display domain).
After changing to the image tting mode using the [
]
button (the shape of the pointer is changed to
), when
the image to be t is touched, or the left button of the
mouse is clicked on the image, the image is displayed
fully using the recognition image display domain, from the
pointer position as the center.
When the image is to be displayed in the image tting mode
with its position xed, place the pointer on the center of the
image before the image tting operation.
[
] button
: Image Real-Size Display Mode (Captured image is
displayed in real-size).
After changing to the image real-size display mode using
the [
] button (the shape of the pointer is changed to ),
when the image to be displayed in real-size is touched, or
the left button of the mouse is clicked on the image, the
image is displayed in real-seize from the pointer position as
the center.
When the image is to be displayed in real-size with its
position xed, place the pointer on the center of the image
before the image real-size display operation.
5.16 "Support pin Pos" Window
3OM-1751
1-691303-001
[2] Recognition Image Display Section
The recognition result is displayed.
[3] Teaching Result
Before
: Displayed are the offset values before the teaching operation.
After
: Displayed are the offset values after the teaching operation.
[4] Operation buttons
Select Head
Each head in the graphic image is provided with a button function. Select the
head where the support pin position teaching is performed.
Select Base
Each base in the graphic image is provided with a button function. Select the
base where the support pin position teaching is performed.
[Conv Wid Move] Button
When this button is pressed, the head is evacuated and the conveyor width is
extended to the limit.
Tch Type Select
The teaching mode is selected in this area.
[Teach Start] Button :
When this button is pressed, the support pin
position teaching is performed automatically.
[Move & Adjust] Button :
When this button is pressed, the support pin's
rst and second positions are taught manually.
[OK] button
When this button is pressed, the teaching results are reected on the machine
operation.
[CANCEL] button
When this button is pressed, the teaching results are cancelled.
[Save] button
When this button is pressed, the teaching results are saved.
•
Teaching Jig
For the PCB support pin position teaching, the PCB support pin position
teaching jig is used.
5.16 "Support pin Pos" Window
3OM-1751
1-701303-001
•
Teaching Procedure
Procedure
(1) Select the head to be used for the teaching operation.
(2) Select the base for which the teaching operation is performed.
(3) Press the [Conv Wid Move] button.
(The conveyor will move to the setup position).
(4) Setup the PCB support pin teaching jig on the two locations; upper left and
lower right.
(5) Select the teaching mode and perform the teaching operation.
[Teach Start] Button
: When selected, go to step [7] and later.
[Move & Adjust] Button
: When selected, go to step [6] and later.
(6) Perform and manual alignment operation for each support pin in the manual
alignment window.
(7) Press the [OK] button.
(8) Press the [Save] button.
(When this button is pressed, the teaching results are saved.)
