3OM-1751 1-1 1 3.3 Feeder Unit When the feeder unit button is pressed, the following window appears. [1] [2] [3] F3A11 [1] Unit select [Feeder] Button : When pressed, the unit with feeder is selected. [Tray JEDEC] Button…
3OM-1751
1-101303-001
3.2 Nozzle Stocker
[2] High-speed stocker
The high-speed stocker type is selected in this selection box.
[High] Button
: When pressed, the unit with high-speed nozzle stocker is
selected.
[High12] Button
: When pressed, the unit with MR12 nozzle stocker is
selected.
Multi-Functional Stocker Shape Selection
F3A9
The multi-functional nozzle stocker shape is selected in this section.
Standard
L1
L2
L3
GS-NM110(KYB-M9640-000).9 Nozzle
GS-NM111(KYB-M96E0-000) : Max.7 Nozzle
GS-NM112(KYB-M96E0-100) : Max.5 Nozzle
GS-NM113(KYB-M96E0-200): Max.3 Nozzle
F3A10
Note
When the nozzle stocker is to be added, an optional unit is required
separately.
•
Nozzle Stocker Setting Procedure
Procedure
(1) Press the button for the installed nozzle stocker in the "Unit Select" area.
Note
For the high-speed nozzle stocker, the stocker type is displayed and for the
multi-functional nozzle stocker, the stocker shape is displayed.
(2) Press the stocker type or stocker shape button.
(3) Press the stocker type or stocker shape button.
3OM-1751
1-11
3.3 Feeder Unit
When the feeder unit button is pressed, the following window appears.
[1]
[2]
[3]
F3A11
[1] Unit select
[Feeder] Button
: When pressed, the unit with feeder is selected.
[Tray JEDEC] Button
: When pressed, the JEDEC size tray feeder
(option) is selected.
[Tray Full Size] Button
: When pressed, the FULL size tray feeder (option)
is selected.
[2] Change Order Guidance
When one of these buttons is pressed, the attachment or removal window for
the "Tray JEDEC" (Option) or "Tray Full-Size" (Option) appears.
"Change Order Guidance" window F3A12
1303-001
Graphic
Development
3.3 Feeder Unit
3OM-1751
1-12
[3] Teach
[Traverse Axis Draw] Button
Using this button, the traverse drawing operation offset teaching for each
machine is performed by teaching the mark position located on the traverse
chuck claw section.
Note
For this operation, the traverse drawing teaching pin is required separately.
[Tray Transfer Tch] Button
Using this button, the tray pallet delivery teaching is performed.
After attaching the multi-layer tray feeder to the main machine, select the
delivery teaching.
If this teaching operation is not performed, the pallet will not be delivered
correctly to the traverse cart.
Reference
Refer to "Chapter 3: Maintenance Menu" in Volume 7 for details.
1303-001
3.3 Feeder Unit
