5 Materials
5-2
M4a/M4e/M4s: Standard Accessories
Part Name Part No.
Qty for
M4a/M4s
Qty for
M4e
Remarks
PIN, MAGNET ASSY
LG0-M9820-00X
※ ※
When the magnet clamp
function is provided, 9 pins
are supplied as standard
accessory.
PIN, PUSH UP (Matrix) (See the optional list)
※ ※
When the matrix clamp
function is provided, 8 pins
of each type (six types in
total) or an arbitrary 48 pins
are supplied as standard
accessory.
Selections:
for 0.5mm
thickness, 1.0mm, 1.2m,
1.6mm, or 2.0mm.
HNS. PRE-PROCESS LG0-M56K0-10X (1) (1) Signal
Cable
(Std.)
HNS.POST-PROCESS LG0-M56K0-20X (1) (1)
Signal Cable(SMEMA) LG0-M56K0-00X (2) (2)
Select “Standard” or
“SMEMA” spec..
LCD Monitor
KGT-M5106-01X
1 1 LCD monitor is optional.
Keyboard KW3-M5150-60X 1 1 English keyboard
Mouse KW3-M5169-04X 1 1 Optical Mouse
Conveyor Handle LG0-M90B9-000 1 1
Lens Cleaner Set LG0-M89A4-000 1 1
Needle Wire KV8-M8887-00X 1 1 For nozzle cleaning
Silicone Grease LG0-M89AB-000 1 1
Vacuum Gauge Set LC1-M89A5-00X 1 1
Separator Assy LG0-M3418-011 12 (12~24) In case of M4e/M4s, the
number differs depending on
the Feeder bank specification.
Parameter FD 1 1
Data FD 1 1
5 Materials
5-3
M4a/M4e/M4s Optional Accessories
Part Name Part No. Qty. Remarks
Nozzle( with ID-sticker)
M001
LG0-M7701-00X
※
M002 LG0-M7703-00X
※
M003 LG0-M7705-00X
※
M004 LG0-M7707-00X
※
M005 LG0-M7709-00X
※
M006 LG0-M770B-00X
※
M012 LG0-M770D-00X
※
M013 LG0-M770F-00X
※
M017 LG0-M770H-00X
※
M018 LG0-M770K-00X
※
M019 LG0-M770M-00X
※
M020 LG0-M770P-00X
※
①
M4a/M4s:
Four arbitrary nozzle
assemblies are supplied as
standard accessory.
M4e: Three arbitrary nozzle
assemblies are supplied as
standard accessory.
②One ID sticker is supplied as
spares for each nozzle.
Nozzle ID mark sticker
M001 LG0-M77D0-00X
M002 LG0-M77D1-00X
M003 LG0-M77D2-00X
M004 LG0-M77D3-00X
M005 LG0-M77D4-00X
M006 LG0-M77D5-00X
M012 LG0-M77D6-00X
M013 LG0-M77D7-00X
M017 LG0-M77D8-00X
M018 LG0-M77D9-00X
M019 LG0-M77DA-00X
M020 LG0-M77DB-00X
Fixed Locating Pin
PIN,LOCATE(C30)
LG0-M990A-00X
PIN,LOCATE(D30) LG0-M990B-00X
PIN,LOCATE(C35) LG0-M990C-00X
PIN,LOCATE(D35) LG0-M990D-00X
PIN,LOCATE(C40) LG0-M990E-00X
PIN,LOCATE(D40) LG0-M990F-00X
Selection
Adjustable Locating Pin
PIN,SLIDE ASSY.(RC30)
LG0-M9910-00X
PIN,SLIDE ASSY.(RD30) LG0-M9911-00X
Selection
5 Materials
5-4
PIN,SLIDE ASSY.(LC30) LG0-M9916-00X
PIN,SLIDE ASSY.(LD30) LG0-M9917-00X
PIN,SLIDE ASSY.(RC35) LG0-M9912-00X
PIN,SLIDE ASSY.(RD35) LG0-M9913-00X
PIN,SLIDE ASSY.(LC35) LG0-M9918-00X
PIN,SLIDE ASSY.(LD35) LG0-M9919-00X
PIN,SLIDE ASSY.(RC40) LG0-M9914-00X
PIN,SLIDE ASSY.(RD40) LG0-M9915-00X
PIN,SLIDE ASSY.(LC40) LG0-M991A-00X
PIN,SLIDE ASSY.(LD40) LG0-M991B-00X
Support Pin (Magnet type)
PIN,MAGNET ASSY.
LG0-M9820-00X Fixed type(Std.)
PUSH UP-PIN,A (SPRING) LG0-M9900-30X Spring type
PUSH UP-PIN (MAGNET) LG0-M9900-60X Fixed type (slim)
PUSH UP-PIN (M-SPRING) LG0-M9900-70X Spring type (slim)
Support Pin（Matrix type）
PIN,PUSHUP (05)
LG0-M9901-00X
PIN,PUSHUP (08) LG0-M9902-00X
PIN,PUSHUP (10) LG0-M9903-00X
PIN,PUSHUP (12) LG0-M9904-00X
PIN,PUSHUP (16) LG0-M9905-00X
PIN,PUSHUP (20) LG0-M9906-00X
PCJ-1 LG0-M5C00-00X Set Master
FPS-1 LG0-M5D00-00X PF Presetter
ID SEAL TOOL, ASSY. LG0-M8903-00X
Guide Pin 6.00 LG0-M86A5-00X
Guide Pin 6.01 LG0-M86A5-10X
Reamer 6.01 LG0-M86A6-00X
Reamer 6.02 LG0-M86A6-10X
Used for Feeder Bank.s
Nozzle Cleaning Kit LG0-M5J00-00X With Handle
Air Coupler LG0-M89A1-00X For Hose diameter,
8.5mm/12.5mm
