1005-001 Fig. G1 Fig. G1-1

Fig. G1-1

フレーム部

Freme Section

52

51

53

54

55

52

51

53

54

55

(BASE:Document No.P-311-00X

UNIT-6 Fig.G1-1)

1005-001

Fig. G1 SMEMA

搬送高さ

(PS-S013-01)

SMEMA TRANSFER HEIGHT(PS-S013-01)

1005-001

Fig. G1

Fig. G1-1

Key No. PART No. PART NAME Q’ty

REMARKS

NOTE

51 216R0340 BLOCK_LOCATE 4 40900010AG-001

52 216R0341 BLOCK_LOCATE 4 40900010AG-002

53 221AA056 ROHS_HEX-SCT 8 40900010AG-003

54 221HA007 WASHER 8 40900010AG-004

55 221HA107 WASHER 8 40900010AG-005

PS-S013-01

Fig. G1-1

1005-001

Fig. G1
