12 Machine performance Placement head types SIPLACE SpeedStar (C&P20 P2) SIPLACE MultiStar (CPP) SIPLACE T winS tar (TH) Placement performance The placement performance is inf luenced by the different head c ombinati…
11
Modular machine concept
Example of SIPLACE X4i S
NC
NC
C&P20 P2
C&P20 P2
NC
NC
PA1
PA2
C&P20 P2
COT In
C&P20 P2
PA1 Placement area 1
PA2 Placement area 2
OP Operator panel
C&P20 P2 SIPLACE SpeedStar
NC Nozzle changer
BZ Buffer zone
COT In Changeover table at the inner
position
IN Input area - conveyor
OUT Output area - conveyor
OP
OP
BZ
PLEASE NOTE: For all possible head configurations please refer to section Machine performance from page 12.
COT In
COT In
COT In
IN
OUT
OUT
BZ
IN
12
Machine performance
Placement head types SIPLACE SpeedStar (C&P20 P2)
SIPLACE MultiStar (CPP)
SIPLACE TwinStar (TH)
Placement performance
The placement performance is influenced by the different head combinations and head positions, plus the conveyor
configurations. Individual options and customized applications also influence the placement performance. On
request, ASM can calculate the actual performance of your product on your machine configuration.
IPC value [components/h]
According to the vendor-neutral conditions of the IPC 9850 standard published by the Association of Connecting
Electronics Industries.
SIPLACE benchmark value [components/h]
The SIPLACE benchmark value is measured during the machine acceptance tests. It corresponds to the conditions
set out in the ASM scope of service and supply.
SIPLACE X2 S
See the note above for definition of placement performance values.
Machine Placement area 1 Placement area 2 IPC value Benchmark
value
X2 S-A C&P20 P2 C&P20 P2 65,000 75,000
C&P20 P2 CPP_L 51,200 59,500
C&P20 P2 CPP_H 49,250 57,000
CPP_L CPP_L 37,400 44,000
CPP_H CPP_H 33,500 39,000
CPP_L CPP_H 35,450 41,500
X2 S-B C&P20 P2 TH 37,000 42,500
CPP_L TH 23,200 27,000
CPP_H TH 21,250 24,500
X2 S-C TH TH 9,000 10,000
SIPLACE X3 S
See the note above for definition of placement performance values.
Machine Placement area 1 Placement area 2 IPC value Benchmark
value
X3 S-A C&P20 P2 / C&P20 P2 C&P20 P2 97,500 112,500
C&P20 P2 / C&P20 P2 CPP_L 83,700 97,000
C&P20 P2 / C&P20 P2 CPP_H 81,750 94,500
CPP_L/CPP_L CPP_L 57,375 67,500
CPP_H / CPP_H CPP_H 50,250 58,500
CPP_L/CPP_L CPP_H 54,150 63,500
X3 S-B C&P20 P2 / C&P20 P2 TH 69,500 80,000
CPP_L/CPP_L TH 41,900 49,000
CPP_H / CPP_H TH 38,000 44,000
X3 S-C CPP_H/TH TH 25,750 29,500
X3 S-D TH / TH TH 12,500 14,000
CPP_H = Multistar CPP in high assembly position
CPP_L = Multistar CPP in low assembly position
13
Machine performance
Placement head types SIPLACE SpeedStar (C&P20 P2)
SIPLACE MultiStar (CPP)
SIPLACE TwinStar (TH)
SIPLACE X4 S
Placement performance
For a definition of placement performance values, see the note on page 12.
Machine Placement area 1 Placement area 2 IPC value Benchmark
value
X4 S-A C&P20 P2 / C&P20 P2 C&P20 P2 / C&P20 P2 130,000 150,000
C&P20 P2 / C&P20 P2 CPP_L/CPP_L 102,400 119,000
C&P20 P2 / C&P20 P2 CPP_H / CPP_H 98,500 114,000
CPP_L/CPP_L CPP_L/CPP_L 74,800 88,000
CPP_L/CPP_L CPP_H / CPP_H 70,900 83,000
CPP_H / CPP_H CPP_H / CPP_H 67,000 78,000
X4 S-B C&P20 P2 / C&P20 P2 CPP_H/TH 86,250 99,500
CPP_L/CPP_L CPP_H/TH 58,650 68,500
CPP_H / CPP_H CPP_H/TH 54,750 63,500
X4 S-C C&P20 P2 / C&P20 P2 TH / TH 74,000 84,000
CPP_L/CPP_L TH / TH 46,500 53,000
CPP_H / CPP_H TH / TH 42,500 48,000
X4 S-D CPP_H/TH TH / TH 28,750 33,000
X4 S-E TH / TH TH / TH 16,000 18,000
SIPLACE X4i S
For a definition of placement performance values, see the note on page 12.
Machine Placement area 1 Placement area 2 IPC value Benchmark
value
X4i S-A C&P20 P2 / C&P20 P2 C&P20 P2 / C&P20 P2 146,000 172,000
C&P20 P2 / C&P20 P2 CPP_L/CPP_L 112,950 133,000
C&P20 P2 / C&P20 P2 CPP_H / CPP_H 107,000 126,000
CPP_L/CPP_L CPP_L/CPP_L 79,900 94,000
CPP_L/CPP_L CPP_H / CPP_H 73,950 87,000
CPP_H / CPP_H CPP_H / CPP_H 68,000 80,000
X4i S-B C&P20 P2 / C&P20 P2 CPP_H/TH 93,675 111,750
CPP_L/CPP_L CPP_H/TH 61,625 72,500
CPP_H / CPP_H CPP_H/TH 55,675 65,500
X4i S-C C&P20 P2 / C&P20 P2 TH / TH 81,350 97,250
CPP_L/CPP_L TH / TH 49,300 58,000
CPP_H / CPP_H TH / TH 43,350 51,000
CPP_H = Multistar CPP in high assembly position
CPP_L = Multistar CPP in low assembly position
