50 Technical data Placement machine dimensions Placement machine center of gravity X = 1400 mm Y = 1050mm Z = 630 mm S = center of gravity These cen ter of gravity coordinates apply for t he machine with a PCB conveyor h…
49
Technical data
Dimensions and setup conditions
Length
a
Without conveyor extension and without hand guard
Without conveyor extension and with hand guard
With input conveyor extension
With input and output conveyor extension
a) Measured at the outer contour of the machine protection.
1915 mm
1948 mm
2191 mm
2433 mm
Width
Outer contour of machine protection
With monitor and keyboard
b
On the component trolley and table position "outermost" (handle folded in)
On the component trolley and table position "outermost" (handle folded out)
b) Optional
2647 mm
2940 mm
2890 mm
3640 mm
Height of machine (for PCB conveyor height 930 mm)
Up to upper edge of monitor
With 2-color indicator lamp
With 3-color indicator lamp
Without indicator lamp (height of packaging)
With folded-up protective covers
1630 mm
1852 mm
1893 mm
1658 mm
2120 mm
Machine ground clearance
(for PCB conveyor height 900 mm)
(for PCB conveyor height 930 mm)
(for PCB conveyor height 950 mm)
195 mm ± 15 mm
225 mm ± 15 mm
245 mm ± 15 mm
Weight
SIPLACE X4i S (machine without component trolley)
SIPLACE X4i S (fully equipped with feeder modules)
SIPLACE X4 S (machine without component trolley)
SIPLACE X4 S (fully equipped with feeder modules)
SIPLACE X3 S (machine without component trolley)
SIPLACE X3 S (fully equipped with feeder modules)
SIPLACE X2 S (machine without component trolley)
SIPLACE X2 S (fully equipped with feeder modules)
3430 kg
4000 kg
3430 kg
4000 kg
3410 kg
3970 kg
3390 kg
3950 kg
Location
c
c) Measured at the outer contour of the machine protection and at the keyboard (without conveyor extension).
5.73 m²
Load per unit area
X-Series S with 4 component trolley X 6.1 kN/m²
Number of machine feet 6
Max. noise emissions 75 dB (A)
Room temperature Between 15°C and 35°C
Atmospheric humidity 30% to 75% (no higher than 45%
on average to prevent any possi-
bility of condensation on the
machine)
50
Technical data
Placement machine dimensions
Placement machine center of gravity
X = 1400 mm
Y = 1050mm
Z = 630 mm
S = center of gravity
These center of gravity coordinates apply for the machine with a PCB conveyor height of
930 mm.
51
Technical data
Maneuvering distances for the
X component trolleys
Pos. Description Location 1/2
D1 Minimum required maneuvering distance for moving the component
trolley out.
800 mm
D2 Recommended maneuvering distance for moving component trolley
out.Distance to adjacent machine/line or the building wall.
1300 mm
L1 Distance from machine center to outer edge of component trolley 1470 mm
