59 Technical data Clearance Values with Input/Output Conveyor Extension All dimensions i n millimeters.
58
Technical data
Clearance dimensions with JTF-M
All dimensions in millimeters.
59
Technical data
Clearance Values with Input/Output Conveyor
Extension
All dimensions in millimeters.
60
Technical data
Transportation and delivery configuration
Description
Within Europe, the machine
is delivered on a robust
wooden pallet. If sent over-
seas, the machine is pack-
aged in a wooden crate.
Configuration when deliv-
ered
• The dual conveyor has a
preset width for lane 1 of
100mm and for lane 2 of
210mm.
• The monitors have been
dismantled.
• The indicator lamp is dis-
mantled.
Transport dimensions and weight
Means of transport
A fork-lift with the following specification will be needed to carry
the machine in its crate:
Length
Width
Height
2000 mm
2960 mm
1620 mm
Weight Dispatch Dispatch
within Europe overseas
3,859 kg 4,359 kg
Fork length
Lifting power
Clear fork width
Min. 1800 mm
Min. 6000 kg
Min. 350 mm
Attachment point
for the fork-lift
Attachment point
for the fork-lift
