Step 11
Fit the connection hose 8mm between the
magnetic valve and the air dryer.
Step 12
Connect the cable at the magnetic valve (colour
not important).
Fit the cable all the way down to the Indel COP.
Change the side at the beginnin
g of the
electronic plate as shown on the picture.
Indel COP connection:
• White: Slot 1, X2, 9
• Brown: Slot 1, X2, 8
Option Air Dryer 00197973-10 / 02 , 2016
11-12 © ASM SIPLACE Mat. Tower Storage Service Manual
Step 13
Attach the sealing tape at the top and bottom
edge of each door.
Notes:
• flush fitting length
• pointed edge to the inner side of the door
Alignment as shown on the picture
Attach the sealing tape as well on top of the
portal
frame.
Alignment is not important.
Fit the clamping section on each inner side of
the door.
00197973-10 / 02 , 2016 Option Air Dryer
SIPLACE Mat. Tower Storage Service Manual © ASM 11-13
Fit the clamping section in all 8 edges of the
doorway.
ATTENTION:
On the lower and upper side has to
be a free distance of around 20 mm allowing the
door to close properly!
Step 14 Humidity sensor
CAUTION : Do not touch the humidity sensor
with bare fingers! Use a thin cloth.
Carefully take the humidity sensor out of the
packing.
Push the sensor in the correct slot with the
mirror plate looking down.
It might be helpful to bend the outer legs wi
th a
small pincer.
