00197973-10 / 02 , 2016 Option Air Dryer
SIPLACE Mat. Tower Storage Service Manual © ASM 11-27
Step 1
Remove the existing sealing tape and attach the
new one on the top and bottom edge of each
door.
Notes:
• flush fitting length
• pointed edge to the inner side of the door
Alignment as shown on the picture
Attach the sealing tape as well on top of the
por
tal frame.
Alignment is not important.
Option Air Dryer 00197973-10 / 02 , 2016
11-28 © ASM SIPLACE Mat. Tower Storage Service Manual
Remove the existing sealing by pulling it off. Fit
the new clamping section on each inner side of
the door.
Remove the existing sealing by pulling it off. Fit
the clamping section in all 8 edges of the
doorway.
ATTENTION:
On the lower and upper side has to
be a free distance of around 20 mm allowing the
door to close properly!
00197973-10 / 02 , 2016 Option Air Dryer
SIPLACE Mat. Tower Storage Service Manual © ASM 11-29
Step 2
Remove all tools and close the doors of the machine. Place the cover above the portal.
Plug in the power connector, connect the compressed air supply and switch on the machine.
Initialize the machine by means of the software.
11.6 Nanofilter Air Dryer
11.6.1 Introduction
This modification instruction describes how to exchange the nano-filter of the membrane dryer on
a SIPLACE Material Tower at customer side.
Spare part number: 03126683-01
Before starting the maintenance, read the Safety instructions carefully.
11.6.2 Tools, Material and Scheduling
For an effective and efficient maintenance, the following resources have to be provided:
Required Tools / Auxiliary Material / Spare parts
Tools: Side cutter small
Auxiliary Material: Cable tie
