3-A AIX-ML T-ID 0705-003 Chapter 3 Data This chapter describes steps in creating, entering, and editing various kinds of data (pattern program data, etc.) required to activate the machine. • Outline of Data • Pattern Pro…

2-41

AIX-MLT-ID

0806-001

3.4 Teaching Operation

(6) Move the object component matrix teaching position for the manual

alignment operation with the image movement buttons until it is

located at the center of the crosshair.

(7) Press the

button in the recognition window to determine the

position.

The recognition window closes and the "Matrix Pitch

XY-Side

Length" window resumes.

(8) The results of the teaching operation appear in the tex

t boxes

entitled "Adj" in the "Matrix Pitch XY-Side Length" window.

(9)

Whenthe[End]buttonispressed,the"ConrmationtoSaving"

dialog box opens, asking you to answer if the data should be saved

or not.

Whenthe[Y

es]buttonispressed,thedataisreectedonthe

component library data is written over the previous one.

Pressing the [No] button cancels the data save operation.

[5] [Feeder No. Tray Set] Button

This button enables you to set the feeder No., the magazine, and the

step for the components to be picked up.

When this button is pressed, a feeder selection becomes possible.

[6]

Comp ID

Displayed is the component library data related to the component on

which a teaching operation is performed.

[7]

Teaching Method

[Tray Zeroing Corner] Button

When this button is pressed, a teaching operation is performed to

specify the component data offsets X and Y.

[Pick-Up First Pos.] and [Pick-Up Last Pos.] Buttons

When these buttons are pressed, the [Center 1-Pt.], [1Point], and [2Point]

buttons are displayed.

Side Lengths X and Y and Pitches X and Y are determined according to

thetaughtrstandlasttakeoutpositions.

3-A

AIX-MLT-ID

0705-003

Chapter 3

Data

This chapter describes steps in creating, entering, and

editing various kinds of data (pattern program data, etc.)

required to activate the machine.

•

Outline of Data

•

Pattern Program

•

Component Library

•

System Setting

3-B
