Station Software 711.1 (R18-1) / Version Description 05/2018 Edition

D1-147192301 The grouping of MTC/WPC components did not work.

D1-147324601

The firmware download onto a new WPC6 failed 2 times with a controller

error 30016.

D1-147775001

Sporadically, the station software stopped during placement with error

message

30016 Unhandled exception error

D1-148003112

eSW: the board was transported from the intermediate section into placement

area 2 but did not get clamped.

D17647-21801 High reject rate for special component (spacer).

D17928-22501

The image was displayed distorted when the "correct position" function was

used.

D17933-45306

The machine tried to recognize an incorrect tray fiducial repeatedly without

stopping.

D18093-25513 The tray data in the generated traceability files was incorrect.

D18093-25601

Download without empty machine: it was not possible to verify components

after a program download while production was running. All feeders were

locked.

D18405-2201

The station software hung up when the pickup position was checked after a

pickup error.

Table 9-3: Corrected errors station software version 710.1 SP1

710.1 Patch 6

Error No.

Error description

D1-145731801 15µm vacuum tools could not be measured.

D1-145333801

Table 1: An error occurred while reading embedded software data from the

subsystem.

D1-145861401

Error message "32507 Product change: Finishing previous product prior to

setup change" and no more boards got into the machine.

D1-145863109

The calculation of the remaining time until the package is used up was not

correct.

D1-146194301

The calculation of the remaining time was not correct when synchronous dual

conveyor was configured.

D18433-301 Production stopped due to an unspecific hardware error of the axis.

D1-138937301

Placement offset of a heavy component because the gantry moved with full

speed during gantry repression.

D1-145522401 The WPC pickup process did not always start at the first pocket.

D18403-209 eSW: The X-axis motor hit the buffer mount of the X axis.

D1-146221801 The WPC pickup position was not calculated correctly.

Table 9-4: Corrected errors station software version 710.1 Patch 6

Station Software 711.1 (R18-1) / Version Description 05/2018 Edition

710.1 Patch 5

Error No.

Error description

D1-140785106

eSW: boards without board barcode required manual confirmation when they

were transported into the next machine.

D1-142933001

eSW: PCB-A interface: the board did not drive into the machine when the

acceleration was too small (< 1400 mm/s²).

D1-143801301

When the acceleration values were taught at the station, the x-axis values

were not transferred.

D1-145171201 Although the panel was marked with an ink spot, it got assembled.

D1-145202821 Restoring the conveyor configuration after mapping did not work.

D1-145232501 The software hung up after having sent a job.

D1-145282601

When conveyor lane 2 was calibrated, the conveyor control stopped with error

message

ISS software is not responding

D1-145398946

eSW: although there was no board in the output area, the machine displayed

one and could not continue production.

D1-145422501

eSW: the board moved directly from PA2 to the next machine; it did not stop

in the output area if the next machine was blocked.

D1-145571791

D1-145633801

D1-145658101

There was an IPC communication error when you pressed the display,

check and setup feeders button on the station software and the view

changed to

deactivated feeders

D1-145603609

D1-143839501

Sporadically the station software stopped during placement with error

message

30016 Unhandled exception error

D1-145691301 During production, gantry 2 stopped without any warning or error on the GUI.

D18294-3901 eSW: error message 35200 Board has not arrived in specified section.

Table 9-5: Corrected errors station software version 710.1 Patch 5

710.1 Patch 4

Error No.

Error description

D1-135126702 Head Verification: DP rotation and segment offset up tests were not possible.

D1-135126745

The Z axis movement and vacuum calibration tests failed but the machine

was ok.

D1-136288601 The board was transported into the input area and was not moved further.

D1-137766301 The teaching of acceleration values failed and component got lost.

D1-138967301 The use of an alternative LDU on the same table was not supported.

D1-139882801

The WPC tray was still moving when the head was ready for pick up. This

slowed down the machine.

D1-140734101

Head cycle count did not match between SIPLACE Pro optimized results and

actual machine run.

D1-141055501

Error message 35026 Pickup location is not ready although the

feeder seemed to be ready.

D1-141676501

Pocket recognition after a manual teaching process added the new position

value to the formerly detected one.

Station Software 711.1 (R18-1) / Version Description 05/2018 Edition

D1-141676541

The gripper got lost and the machine reported 30482 Z axis is beyond

maximum position, position is in empty space, segment: 2

but did not stop.

D1-142007061

eSW: conveyor: changing conveyor mode from double back to single did not

work.

D1-142180007

Measuring all components after placement lead to the error message: y

axis 1 power supply not sufficient

D1-142505151

The station reported 40034 CAUTION: Do not move gantry! The

head lost a nozzle

although the gripper was not lost.

D1-142765001

Fill level change

after

consumed

event from station caused problems.

D1-142800301

Sporadically the station SW stopped during placement with error message

30016 Unhandled exception error

D1-142915801 During production run there was no placement in placement area 2.

D1-143004545 The station could not be stopped and had to be switched off.

D1-143141501

The current of the lifting table motor was too low at conveyor motor

verification.

D1-143195601

Suddenly the station software did not react any longer and had to be

rebooted.

D1-143204201

eSW: The lifting table moved downwards into the mechanical limit as soon as

a board arrived in the placement area.

D1-143231401

The multistep calibration stopped with an error message when the results

were saved.

D1-143475401

The SIPLACE Pro components which were assigned to specific reference

designators differed to those in SIPLACE Pro.

D1-143605001 Plausibility check showed wrong error message.

D1-143635102 eSW: the overlapping of the X- and Z-axes during pick up was not correct.

D1-143683801

A new program was downloaded with activated snap in verification.

Afterwards the snap selection ran endlessly. Anschließend lief die Snap-

Auswahl in Endlosschleife.

D1-143697601 The polarity check during re-filling did not work.

D1-143744601 The X feeder index LED did not show the correct status.

D1-143783201

The whispering of board barcode was active although the machines were not

defined as a cluster.

D1-143958512 The component in the tray could not be reached.

D1-144006701

The software hung up when the changes of OSC component teaching were

saved.

D1-144031036

The station GUI was not refreshed after download. The previous job was

displayed on the screen.

D1-144063301

A wide connector on TH segment 2 was wiped off by the aperture collar of

segment 1.

D1-144172401 Vision dumps could not be filtered by location.

D1-144388801

During preparation work for new production there was the error message

32602 The software has stopped unexpectedly. Shut down

Windows, then restart the station

D1-144618801 Components were not available for teaching.
