Siplace TX-设备参数-EN
www .asm-smt.com SIPLACE TX Specification TX from SR .710.1, 06/2017 Edition Top quality for high-volume production
www.asm-smt.com
SIPLACE TX
Specification TX from SR.710.1, 06/2017 Edition
Top quality for high-volume production
3
SIPLACE TX
Content
Overview of technical data 5
Maximum values 5
SIPLACE TX 6
Machine description 6
Machine performance 7
SIPLACE placement heads 8
General 8
SIPLACE SpeedStar (C&P20 P) 9
SIPLACE MultiStar (CPP) 10
SIPLACE TwinStar (TH) 11
Nozzle changer 12
Technical data 13
Board conveyor 14
Flexible dual conveyor 14
Technical data 15
Alternating placement mode 16
PCB warpage 17
Component feeding 19
Component trolley 19
SIPLACE SmartFeeder X 20
Alternative SIPLACE modules 21
JTF-ML 2 22
SIPLACE Vision 23
High Placement Performance and Best Quality 23
Component recognition 25
PCB position recognition 27
Barcode and Data Matrix Codes 29
Options 31
ASM Software Products 32
Overview 32
SIPLACE station software 33
General 33
Technical data 34
Electrical ratings, energy consumption and compressed air supply 34
Dimensions and setup conditions 36
Machine dimensions 37
Machine center of gravity 37
Maneuvering distances for component trolleys 38
Machine foot clearances 39
