16 Board conveyor I-Placement Alternating placement mode Alternating placement or I-Placement mode Distance of outer conveyor edges: 562 mm, 2 lanes, outer conveyor edges fixed Alternating placement mode Distance of oute…

100%1 / 52
15
Board conveyor
Technical data
Flexible dual conveyor Dual conveyor in
"single conveyor"
(optional) mode
Board dimensions
(length x width
a
)
a) When using board widths > 375 mm, make sure that the peripheral modules can also process these
board widths.
50 mm x 45 mm to
375 mm x 260 mm
50 mm x 45 mm to
375mm x 460mm
Stationary conveyor side Outside
Right / right
Left / left
Outside
Automatic electrical width adjust-
ment
Standard
PCB thickness
Standard 0.3 mm to 4.5 mm
PCB warpage See page 17
PCB weight
b
Standard
b) The board weight value refers to the weight of the board plus the weight of the components.
Max. 2.0 kg Max. 2.0 kg
Clearance on PCB underside 25 mm
PCB conveyor height
Option
Standard
Option SMEMA
900 mm
930 mm
950 mm
Type of interface
Standard SMEMA
Component-free PCB handling
edge
3 mm
PCB changeover time
Dual conveyor 1.3 seconds
c
0 seconds
d
c) With the "Convoy Mode" option. Without this option 1.8 seconds.
d) 0 seconds in synchronous mode
Key information for machines in combination with SIPLACE TX:
When setting up a machine (S; F, HS, HF, X or D-Series) next to a SIPLACE TX, be aware that there is limited room
between the two machines. In these cases, use a suitable conveyor extension to create room of 0.5m for the operator
between the two machines.
16
Board conveyor
I-Placement
Alternating placement mode
Alternating placement or
I-Placement mode
Distance of outer conveyor
edges: 562 mm, 2 lanes, outer
conveyor edges fixed
Alternating placement mode
Distance of outer conveyor
edges: 562 mm, 2 lanes, right
conveyor edges fixed
a
Alternating placement mode
Distance of outer conveyor
edges: 460 mm, dual conveyor
in single conveyor mode, right
conveyor edge fixed
a
Max. 260
Movable conveyor side
Stationary conveyor side
a) The diagram only shows settings with a fixed righthand conveyor edge. A setting with the stationary conveyor
edge on the left is also possible. All dimensions in millimeters.
Max. 260
281
562
Min. 35
281
179
Max. 260
281
Min. 35
Max. 260
562
Max. 460
Adjustable conveyor side position and max. PCB width
Conveyor side position Max. PCB width Distance of fixed side for various fixed side position
settings
Inside Right or left
231 mm 210 mm 462 mm 248.5 mm
268 mm 250 mm 536 mm 285.5 mm
281 mm 260 mm 562 mm 298.5 mm
Machine center
Machine center
Machine center
