G -S013-06 1012-003 25 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE 14 6301433363 PLA TE 1→0 803DD-210-014 21 1DB394 15 6301370309 PLA TE 1→0 803DD-210-015 21 1DA584 31 6301260068 NAME PLA TE,INDEX 1→0 803DD…
G -S013-06
0909-002
24
EXCHANGE
65
61
.
52
.
31
42
15
49
14
31
15
49
14
65
61
.
52
.
42
59
37
37
74
73
71
76
72
79
78
.
77
.
CV-G100
取付
Main Machine Modification(Left-Front)
本体対応（左前）
For Attaching CV
-G100
G -S013-06 G -S013-06
Fig. DD-1
カッタ部
B,C
- ベースフレーム
Cutter Section B,C-Base Frame
G -S013-06
1012-003
25
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
14 6301433363 PLATE 1→0 803DD-210-014 211DB394
15 6301370309 PLATE 1→0 803DD-210-015 211DA584
31 6301260068 NAME PLATE,INDEX 1→0 803DD-210-231 6P460124
42
6301538662 SUPPORT 1→0 803DD-210-072 211K3356
49 6301366906 GUIDE 1→0 803DD-210-049 212A2219
52
6300007527 BOLT,HEX-SCT 5→0 M3X10 221A0007
59
4111408007 SCR TRS 5X6
10→6
M5X6 TRS 221E0536
61 4111412806 WASHER SPR 3 5→0 SW3 221H0281
65
4111413902 WASHER V 3X7X0.5 5→0 FW3 221H0312
71
6301376950 NAME PLATE,INDEX 1
803DDA210010-A001
6P460158
72 6301366852 PLATE 1
803DDA210010-A002
211DA551
73 6301366906 GUIDE 1
803DDA210010-A003
212A2219
74 6301370309 PLATE 1
803DDA210010-A004
211DA584
75 6301442440 SUPPORT(SUPPORT) 1
803DDA210010-A005
211K3213
76 4111408007 SCR TRS 5X6 6
803DDA210010-A006
221E0536
77 6300007510 BOLT,HEX-SCT 5
803DDA210010-A007
221A0006
78 4111412806 WASHER SPR 3 5
803DDA210010-A008
221H0281
79 4111413902 WASHER V 3X7X0.5 5
803DDA210010-A009
221H0312
DD-1
G -S013-07
0909-002
26
EXCHANGE
31
42
15
49
14
65
61
.
52
.
59
72
73
74
71
75
79
78
.
77
.
37
65
61
.
52
.
31
42
15
49
14
37
59
CV-G100
取付
Main
Machine Modification(Right-Rear)
本体対応（右奥）
For Attaching CV-G100
G -S013-07 G -S013-07
Fig. DD-1
カッタ部
B,C
- ベースフレーム
Cutter Section B,C-Base Frame
