PART No. ｲﾗｽﾄ No. REF No. PAR T NAME REMARKS Q'TY 8 ﾍｯﾄﾞ 部(駆動部2) HEAD S ECT.(DRIVING S ECT.-2) 部 品 名 品 番 個数 備 考 R 1 R 2 1 203 108620910501 PLATE ﾌ ﾟﾚｰﾄ 1 204 1086209106 PLATE ﾌﾟﾚｰﾄ 8 208 108620900702 COLLAR ｶﾗｰ 8 20…
ﾍｯﾄﾞ部(駆動部2)
HEAD SECT.(DRIVING SECT.-2)
8
FN610061358AA_03-2
M95
PART No.
ｲﾗｽﾄ
No.
REF
No.
PART NAME
REMARKS
Q'TY
8
ﾍｯﾄﾞ部(駆動部2)
HEAD SECT.(DRIVING SECT.-2)
部 品 名 品 番 個数
備 考
R
1
R
2
1203 108620910501
PLATE ﾌ
ﾟﾚｰﾄ
1
204 1086209106
PLATE ﾌﾟﾚｰﾄ
8
208 108620900702
COLLAR ｶﾗｰ
8209 N210101473AA
COLLAR ｶﾗｰ
8210 1086209043
SPRING ｽﾌﾟ
ﾘﾝｸﾞ
4
211 N210095776AA
PULLEY ﾌﾟｰﾘｰ
4
212 N210095775AA
PULLEY ﾌﾟｰﾘｰ
1216 N210046993AA
COVER ｶﾊ
ﾞｰ
8228 108620922802
HANGER ﾊﾝｶ
ﾞｰ
8
229 1086289291
HOUSING ﾊｳｼﾞﾝｸﾞ
8232 108628946101
SHAFT ｼｬﾌﾄ
8236 1086209236
STOPPER ｽﾄｯﾊ
ﾟ
HC-BH0236-S11 S
8
N201
N510029993AA
MOTOR ﾓｰﾀ
SFC-010DA-T006
8
N202
N644SFC0-195
COUPLING ｶｯﾌﾟﾘﾝｸﾞ
626ZZ
24
N204
XLC626ZZ
BALL BEARING ﾎﾞｰﾙﾍﾞｱﾘﾝｸﾞ
WSSB13-6-2
8
N206
N986WSSB1362
WASHER ｻ
ﾞｶﾞﾈ
KSH04-M5
8
N207
N431KSH04M5
FITTING ﾂｷﾞﾃ
696ZZ1MC2
16
N208
N510003424AA
BEARING ﾍﾞｱﾘﾝｸﾞ
6702LLF
16
N209
N510003270AA
BEARING ﾍﾞｱﾘﾝｸﾞ
M3X3-45H A2J (Trivale
16
N211
N510018358AA
HEX. SOCKET SET SCREW ﾛｯｶｸｱﾅﾂｷﾄﾒﾈｼ
ﾞ
6801ZZC2
8
N213
N510003278AA
BEARING ﾍﾞｱﾘﾝｸﾞ
ISTW-12
8
N214
KXF0DAYAA00
RETAINING RING C-TYPE, SHAF ﾏﾙ S ｶﾞﾀ ﾄﾒﾜ
ACB3-35
4
N216
N986ACB335
BOLT ﾎ
ﾞﾙﾄ
A-42-J-3
1
N222
N980A42J3
KNOB ﾄｯﾃ
M6X20-4.8 A2J (Trival
2
N223
N510018204AA
FLUSH HEAD SCREW ｻﾗｺﾈｼﾞ
M3X8-10.9 A2S (Trival
9
N234
N510017342AA
HEX. SOCKET HEAD CAP BOLT ﾛｯｶｸｱﾅﾂｷﾎﾞﾙﾄ
No.2 3 S A2S (Trivale
9
N235
N510018328AA
SPRING WASHER ﾊﾞ
ﾈｻﾞｶﾞﾈ
3 10H A2S (Trivalent)
9
N236
N510018495AA
ROUND PLAIN WASHER ﾐｶﾞｷﾏﾙﾋﾗｻﾞｶﾞﾈ
LSAGT8C2R236E671
8
N237
N513LSAG-B29
BALL SPLINE ﾎﾞｰﾙｽﾌﾟﾗｲﾝ
4 10H A2J (Trivalent)
16
N238
N510018479AA
ROUND PLAIN WASHER ｺｶﾞｶﾏﾙﾋﾗｻﾞｶﾞﾈ
BNK0812S-3GS+156.5LC7
8
N240
N643BNK0-610
BALL SCREW ﾎﾞ
ｰﾙﾈｼﾞ
M3X10
16
N242
N986YYYY-866
SCREW ﾈｼﾞ(ﾃｲﾄｳﾛｯｶｸｱﾅﾂｷ)
M96
