MODEL CD-G50
0702-003
18
154
153
.
152
.
156
133
.
165
162
161
151
CD-G50
電装部
CD-G50 ELECTRICAL SECTION
Fig. LF-2
分配基板
Distribute P.C.B.
MODEL CD-G50
1012-005
19
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
151 6301605081 BRACKET 1 806LF-120-151 211FC267
152 6300007749 BOLT,HEX-SCT 2 806LF-120-152 221A0029
153
4111416705 WASHER SPR 5 2 806LF-120-153 221H0287
154
4111414107 WASHER V 5X10X1 2 806LF-120-154 221H0318
155
4110407803 SCR PAN 3X12 6 806LF-120-155 221E0489
156
4111191909 WASHER V 3X7X0.5 6 806LF-120-156 221H0311
161
6301340913 P.C.B,MOUNT 1 -U97 806LF-120-161 4B11
1509
162 6301334172 CORD(ASSY CABLE) 1 806LF-120-162 4W202974
163
6300606409 ACCESSORY,WIRING 1 806LF-120-163 23N30173
165
6301334189 CORD(ASSY CABLE) 1 806LF-120-065 4W202975
LF-2
G -S052-01
0909-003
20
161
156
.
151
.
161
156
.
152
.
101
102
103
See Fig.LE-1
Key No.4
161
156
.
152
.
162
157
.
153
.
161
156
.
151
.
コプラナリティチェックユニット取付
Main Machine Modification(Left-Rear,Right-Front)
本体対応（左奥、右前）
For Attaching Coplanarity Check Unit
G -S052-01 G -S052-01
Fig. LE-2
ベース部
Base Section
