W ARNING Precautionary Measures in Maintenance and Inspection Work 0004-002 8 Tg0249-PM-MM Before performing maintenance work, turn off the power switch and the air source of the machine and lock the power breaker using …
Contents
Page
Section 5 Touch Screen ................................................................... 5- 1
1. SCREEN ADJUSTMENT Display ................................................... 5- 2
2. RGB (Red-Green-Blue Signal) Adjustment ..................................... 5- 5
3. DATA SAVE MODE Display ............................................................ 5- 6
9910-001 7 Tg0249-PM-MM
WARNING
Precautionary Measures in Maintenance and Inspection Work
0004-002 8 Tg0249-PM-MM
Before performing maintenance work, turn off the
power switch and the air source of the machine
and lock the power breaker using the padlock.
• Designate a personnel who can have charge of the
padlock key.
•
If the provided padlock is lost or damaged, purchase its
substitute.
Power Breaker
Padlock
(No. 2500 30 MM)
Precautionary Measures in Maintenance and
Inspection Work
Padlock
Main Valve
Section 1
Periodic Inspections
9910-001 1-1 Tg0249-PM-MM
