TRAVERSE CART SECTION(FULL)
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
261 KYC-M184C-00 222D0442 BEARING_RADIAL 4
262 KYC-M184D-00 222E0020 BEARING_THRUST- 4
263 91312-06016 221AA043 BOLT,HEX.SOCKET HEAD 4 M6L16
264 92902-06200 221HA106 WASHER 4 FW6
265 92902-06100 221HA006 WASHER,SPRING 4 SW6
266 99009-10400 221K0076 CIRCLIP 12 C RING 10
272 KYB-M8515-00 1005AB0W PIPE_FITTINGS 2
278 KYC-M185P-00 0921D302 TUBE_D6 1
288 91312-06040 221AA048 BOLT,HEX.SOCKET HEAD 4 M6L40
289 91312-08030 221AA058 BOLT,HEX.SOCKET HEAD 4 M8L30
293 92902-06200 221HA106 WASHER 4 FW6
294 92902-08200 221HA107 WASHER,PLAIN 4 FW8
2A2 92902-08100 221HA007 WASHER,SPRING 8 SW8
2A3 92902-06100 221HA006 WASHER,SPRING 4 SW6
2B8 91312-06025 221AA045 BOLT,HEX.SOCKET HEAD 4 M6L25
