– 70 – E4 E4 POSITIONING UNIT 3 Frame L 1304-001 229 223 240 242 228 230 224 238 236 237 232 212 212 233 222 227 243 227 226 225 233 234 235

100%1 / 84
– 69 –
CUTTER SECTIONN
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
2 KYC-M3T01-00 1015H237 DUSTCHUTE-TRAY 1
3 90990-66J017 221DA221 RO_MACHIN_SCREW 2 TRS M5L8
4 90990-66J012 221DA207 SCREW,TRUSS HEAD 2 TRS M4L6
6 KYC-M3T00-00 1015H22Y SUPPORT 1
7 90990-01J144 221AA100 BOLT,HEX.S/H WW 4 M4L8
1304-001
– 70 –
E4
E4 POSITIONING UNIT
3 Frame L
1304-001
229
223
240
242
228
230
224
238
236
237
232
212
212
233
222
227
243
227
226
225
233
234
235
– 71 –
POSITIONING UNIT
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
212 91312-05012 221AA030 ROHS_HEX-SCT 2 M5L12
222 KYC-M3J00-00 1010BJ0Q BLOCK_LEVER_R 1
223 KYC-M3J06-00 1010BJ1U CYLINDER_BKT-R 1
224 KYC-M3J05-00 1010BJ0P LEVER 1
225 KYC-M3J0A-00 0929E00W SHAFT 1
226 KYC-M3J0B-00 0929E00Y COLLAR 1
227 90933-01J002 222D0008 BEARING,RADIAL 2
228 KYC-M3J04-00 0929E01L PIN_CYLINDER 1
229 $M-5ALU-4 225F0260 PIPE_FITTINGS 2
230 KYC-M3J0E-00 0929E01M D_KNUCKLE_JOINT 1
232 KYC-M3J0D-00 0929E01H TENSION_SPRING 1
233 90990-66J012 221DA207 SCREW,TRUSS HEAD 4 TRS M4L6
234 91312-05016 221AA031 ROHS_HEX-SCT 1 M5L16
235 95302-05600 221FA009 NUT,HEXAGON 2 M3
236 91312-06030 221AA046 BOLT,HEX.SOCKET HEAD 1 M6L30
237 95302-06600 221FA011 NUT,HEXAGON 1 M6
238 90990-02J026 221CA007 SCREW,SET 1 SET_M5L6
240 91312-05008 221AA028 BOLT,HEX.SOCKET HEAD 2 M5L8
242 90440-01J040 221KB001 CIRCLIP 1 RING_E4
243 99009-15400 221K0079 CIRCLIP 1
1304-001
