P-332-001_MULTI-LAYER_TRAY-FEEDER - 第80页
– 74 – E4 5 Air Piping 1303-001 402 403 401 402 403 From Main Body See Fig E4-3 Key No.228 See Fig E4-4 Key No.328 See Fig E4-4 Key No.313
– 73 –
POSITIONING UNIT
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
310 KYC-M3J03-00 09294021 ASSY-VALVE 1
312 91312-05012 221AA030 ROHS_HEX-SCT 2 M5L12
313 91312-03006 221AA005 BOLT,HEX.SOCKET HEAD 2 M3L6
321 KYC-M3J02-00 0929401Y ASSY-SENSOR 1
322 KYC-M3J00-00 1010BJ0Q BLOCK_LEVER_R 1
323 KYC-M3J06-00 1010BJ1U CYLINDER_BKT-R 1
324 KYC-M3J05-00 1010BJ0P LEVER 1
325 KYC-M3J0A-00 0929E00W SHAFT 1
326 KYC-M3J0B-00 0929E00Y COLLAR 1
327 90933-01J002 222D0008 BEARING,RADIAL 2
328 KYC-M3J04-00 0929E01L PIN_CYLINDER 1
329 $M-5ALU-4 225F0260 PIPE_FITTINGS 2
330 KYC-M3J0E-00 0929E01M D_KNUCKLE_JOINT 1
331 KYC-M3J0C-00 0929E01D PLATE 1
332 KYC-M3J0D-00 0929E01H TENSION_SPRING 1
333 90990-66J012 221DA207 SCREW,TRUSS HEAD 4 TRS M4L6
334 91312-05016 221AA031 ROHS_HEX-SCT 1 M5L16
335 95302-05600 221FA009 NUT,HEXAGON 2 M3
336 91312-06030 221AA046 BOLT,HEX.SOCKET HEAD 1 M6L30
337 95302-06600 221FA011 NUT,HEXAGON 1 M6
338 90990-02J026 221CA007 SCREW,SET 1 SET_M5L6
339 90112-02J006 221AA001 BOLT,HEX.SOCKET HEAD 2 M2L6
340 91312-05008 221AA028 BOLT,HEX.SOCKET HEAD 2 M5L8
341 90166-12J208 221DA061 SEMS_PANHEADSCR 1 PAN M2L8 SW+FWS
342 90440-01J040 221KB001 CIRCLIP 1 RING_E4
343 99009-15400 221K0079 CIRCLIP 1
1303-001
– 75 –
POSITIONING UNIT
No.
Part No.
Part Name Qty. Detail
Yamaha Hitachi
401 KYB-M3J1H-00 0929E105 TUBE D6 1
402 KYC-M3J0F-00 1005AB0V PIPE_FITTINGS 2
403 KYB-M3J2K-00 0929E106 TUBE D4 1
1304-001
