MEMO
MODEL TCM-3600J
9811-001
12- 5
Key No. PART No. PART NAME Q'ty REMARKS
52 411 008 1706 WASHER SPR 4 2 SW4 F
53 411 161 9007 SCR PAN 4X35 2 M4X35 PAN
54 630 001 0220 WASHER 2 BW5
55 411 141 6705 WASHER SPR 5 2 SW5
56 630 000 8401 BOLT,HEX-SCT 2
57 630 062 0528 BRACKET 1 703R--01B-067
58 411 141 4008 WASHER V 4X9X0.8 2 FW4
59 411 141 2905 WASHER SPR 4 2 SW4
60 630 000 7619 BOLT,HEX-SCT 2 M4X8
61 411 113 5002 SCR FLT 4X12 2 M4X12 FLT
62 630 071 6399 BRACKET 1 703R--01B-066
63 411 141 4008 WASHER V 4X9X0.8 2 FW4
64 411 141 2905 WASHER SPR 4 2 SW4
65 630 000 7619 BOLT,HEX-SCT 2 M4X8
66 411 113 9109 SCR TRS 5X10 1 M5X10 TRS
71 630 064 9598 COVER 1 703R--01B-070
72 411 113 9109 SCR TRS 5X10 6 M5X10 TRS
73 630 064 9642 BRACKET 1 703R--01B-072
74 411 141 4107 WASHER V 5X10X1 2 FW5
75 411 141 6705 WASHER SPR 5 2 SW5
76 630 000 7732 BOLT,HEX-SCT 2 M5X8
77 630 065 2376 MECH PARTS(MAGNET CATCHE) 1 703R--01H-015
78 411 119 1909 WASHER V 3X7X0.5 2 FW3 F
79 411 086 4408 WASHER SPR 3 2 SW3 F
80 411 042 0703 SCR PAN 3X8 2 M3X8 PAN
NOTE
MEMO
MODEL TCM-3600J
9811-001
後面カバー部 REAR COVER SECTION
Fig.13-1 ガード支柱 Guard Stay
D
B
D
A
C
C
2-1
4-3
5-1
4-2
4-1
25
26
27
18
20
21
22
23
15
15
17
82
82
81
19
20
21
22
23
25
26
27
16
16
17
62
63
64
65
63
64
65
34
57
58
59
60
57
58
59
60
36
37
38
39
40
38
39
40
39
38
37
38
39
40
35
36
62
63
64
65
64
65
14-1
14-2
7
8-1
6-1
7
8-1
6-1
1-7
1-6
14-3
6
5
5-1
5
5-1
5
7
8
6
7
8
4-3
4-2
4-1
3-1
1-1
1-2
6-1
5-1
7
8
5
5-1
5
5
5-1
2-2
3-2
A
20
75
76
75
76
24
69
72
73
74
70
72
73
74
72
69
73
74
20
24
B
9
9-1
10
10-1
11
13
12
12-1
58
56
59
60
29
33
32
31
28
31
32
33
28
30
28
28
31
32
33
33
32
31
61
71
71-1
72
73
74
72
73
74
71
71-1
TCM-3600J
