Parameter Definition
Right Feed Delay This parameter sets a time delay on the board stop to allow for irregular shaped boards
when fed from the right.
Minimum 0sec
Maximum 3secs
Increments 0.1sec steps
NOTE
Not used while remote board stop is fitted.
Alignment Weighting This is only used in 2 fiducial mode and sets a value determining how much of the
fiducial spacing error is assigned to fiducial 2.
Minimum 0%
Maximum 100%
Increment 1%
Default 50% (see vision system)
X Align Weighting This is only used in 3 fiducial mode and sets a value determining where the X axis
alignment should be optimized.
Minimum 0%
Maximum 100%
Increment 1%
Default 50% (see vision system)
Y Align Weighting This is only used in 3 fiducial mode and sets a value determining where the Y axis
alignment should be optimized.
Minimum 0%
Maximum 100%
Increment 1%
Default 50% (see vision system)
Alignment Mode This parameter determines the mode used for board to screen alignment. The Non Vision
option is only available from the configuration file. Options available are:
2 fiducial; 3 fiducial.
Default 2 fiducial
Fiducial 1 X coordinate Distance of first fiducial from the right or left hand edge of the board (configuration
dependent).
Minimum 1mm
Maximum Board Length
Increment 0.1mm
Default 1mm
Fiducial 1 Y coordinate Distance of the first fiducial from the front edge of the board.
Minimum 1mm
Maximum Board Width
Increment 0.1mm
Default 1mm
Fiducial 2 X coordinate Distance of second fiducial from the right or left hand edge of the board (configuration
dependent).
Minimum 1mm
Maximum Board Length
Increment 0.1mm
Default 1mm
Fiducial 2 Y coordinate Distance of the second fiducial from the front edge of the board.
Minimum 1mm
Maximum Board Width
Increment 0.1mm
Default 1mm
Fiducial 3 X coordinate Distance of third fiducial from the right or left hand edge of the board (configuration
dependent).
Minimum 1mm
Maximum Board Length
Increment 0.1mm
Default 1mm
Software Version 6 User Manual 1.95
MACHINE PROGRAMMING
MENU PARAMETERS
Parameter Definition
Fiducial 3 Y coordinate Distance of the third fiducial from the front edge of the board.
Minimum 1mm
Maximum Board Width
Increment 0.1mm
Default 1mm
Select Mark X Distance of the select mark from the right or left hand edge of the board (configuration
dependent).
Minimum 0mm
Maximum Board Length
Increment 0.1mm
Default 148.5mm
NOTE
Only used while Selective Print/Pass is enabled in Set Preferences.
Select Mark Y Distance of the select mark from the front edge of the board.
Minimum 0mm
Maximum Board Width
Increment 0.1mm
Default 13mm
NOTE
Only used while Selective Print/Pass is enabled in Set Preferences.
Board 1 Fiducial Type This determines the type of model to be used for this fiducial. Options are Circle;
Rectangle; Diamond; Triangle; Double Square; Cross; Video model. (see vision system)
Board 2 Fiducial Type This determines the type of model to be used for this fiducial. Options are Circle;
Rectangle; Diamond; Triangle; Double Square; Cross; Video model. (see vision system)
Board 3 Fiducial Type This determines the type of model to be used for this fiducial. Options are Circle;
Rectangle; Diamond; Triangle; Double Square; Cross; Video model. (see vision system)
Select Mark Type This determines the type of model to be used on the board for the select mark. Options
are Circle; Rectangle; Diamond; Triangle; Double Square; Cross; Video model. (see
vision system)
NOTE
Only used while Selective Print/Pass is enabled in Set Preferences.
Screen 1 Fiducial Type This determines the type of model to be used for this fiducial. Options are Circle;
Rectangle; Diamond; Triangle; Double Square; Cross; Video model. (see vision system)
Screen 2 Fiducial Type This determines the type of model to be used for this fiducial. Options are Circle;
Rectangle; Diamond; Triangle; Double Square; Cross; Video model. (see vision system)
Screen 3 Fiducial Type This determines the type of model to be used for this fiducial. Options are Circle;
Rectangle; Diamond; Triangle; Double Square; Cross; Video model. (see vision system)
Screen Image The position of the image in the screen frame. Options available are EDGE justified and
CENTRE Justified. Edge justified only is permitted for Sanyo and Fuji frames.
NOTE
This parameter is not displayed, if Screen Size in Set Preferences has been selected to
Screen Library.
Custom Screen This option allows user definable screen image positions. Selection of this parameter
activates the Print Area Length, Print Area Width and Distance To Image. Options are:
ENABLED; DISABLED
NOTE
This parameter is not displayed, if Screen Size in Set Preferences has been selected to
Screen Library.
Distance To Image The meaning of this parameter varies, depending on whether an image is centre or edge
justified. For centre justified images, the dimension is the distance from the outside rear
of the screen frame to the centre of the image. For edge justified images, the dimension
is the distance from the outside rear of the screen frame to the front edge of the board.
NOTE
This parameter field only appears if Custom Screen has been selected.
Minimum 306mm
Maximum 645mm
Increments 0.1mm
1.96 User Manual Software Version 6
MACHINE PROGRAMMING
MENU PARAMETERS
Parameter Definition
Print Area Length This is the maximum printable distance in the Y direction, ie the maximum distance the
squeegee can travel, front to back.
NOTE
This parameter field only appears if Custom Screen has been selected.
Minimum 100mm
Maximum 508.5mm
Increments 0.1mm
Print Area Width This is the maximum length of squeegee that could be fitted to the printer, taking into
account screen frame and the amount of mesh surrounding the mask. This is also the
maximum length of paste that can be dispensed.
NOTE
This parameter field only appears if Custom Screen has been selected.
Minimum 100mm
Maximum 510mm
Increments 0.1mm
Screen Adapter The type of screen adapter needed, if any, for the screen to be used for this product.
NOTE
This parameter is not displayed, if Screen Size in Set Preferences has been selected to
Screen Library.
Options available are NONE, 255, SANYO, HERAEUS, 20 X 20 and
12 X 12.
Forward X offset Programmable offset of the print on the board when printing from the rear. A positive
offset moves the print to the right of the board.
Minimum -1.0mm
Maximum +1.0mm
Increment 0.004mm
Forward Y offset Programmable offset of the print on the board when printing from the rear. A positive
offset moves the print to the rear of the board.
Minimum -1.0mm
Maximum +1.0mm
Increment 0.004mm
Forward q offset
Programmable offset of the print on the board when printing from the rear. A positive
offset moves the print in a clockwise direction.
Minimum -1000 arc seconds
Maximum +1000 arc seconds
Increment 2 arc seconds
Reverse X offset Programmable offset of the print on the board when printing from the front. A positive
offset moves the print to the right of the board.
Minimum -1.0mm
Maximum +1.0mm
Increment 0.004mm
Reverse Y offset Programmable offset of the print on the board when printing from the front. A positive
offset moves the print to the rear of the board.
Minimum -1.0mm
Maximum +1.0mm
Increment 0.004mm
Reverse q offset
Programmable offset of the print on the board when printing from the front. A positive
offset moves the print in a clockwise direction.
Minimum -1000 arc seconds
Maximum +1000 arc seconds
Increment 2 arc seconds
Print Mode This parameter sets the mode of operation of the machine. Available modes are:
PRINT/PRINT, PRINT/FLOOD, FLOOD/PRINT, ADHESIVE.
The default is PRINT/PRINT.
Selecting Adhesive from this parameter opens the separation delay and print vacuum
mode.
