Fiducial Monitoring This parameter enables and disables the intelligent fiducial monitoring feature, options are: Smart; Normal The default is Normal. If smart is selected, a set levels menu bar option is available. Set …

When a particular print stroke is being monitored, as the squeegee traverses the

image the pressure being applied is measured and recorded. Any variations in

the load being applied, as a result of insufficient tooling support or underside

components coming into contact with the tooling are noted. Upon completion of

the print stroke, the deviation in the pressure applied over the print stroke is

determined and expressed as the tooling deviation. The tooling deviation is

calculated from the minimum and maximum values and expressed as a

percentage. If the tooling deviation exceeds the permitted threshold, as set by

the Tooling Deviation parameter in the product file, a cyclic log text file called

deviate.dat is written and the following window is displayed:

NOTE

The number of samples is the amount of pressure variations recorded during the

print stroke.

The following menu bar is displayed:

Continue Abort

On selecting Continue printing proceeds until it is interrupted by some other

cause.

On selecting Abort printing is discontinued and the following menu bar is

displayed, to enable the board to be removed from the machine:

Auto

Board

Manual

Board

Exit

If the number of samples (pressure variations) during a print stroke is less than 2

or the minimum value is zero, the error message ‘Failed to determine Tooling

Deviation’ is displayed.

Display Type Sets the type of status page displayed on the monitor, options are:

Type 1; Type 2

The default is Type 1.

2.14 User Manual Software Version 6

SET PREFERENCES

PREFERENCES

Excessive Tooling Deviation

Tooling Deviation : 25.08 %

Number of Samples : 81

Check the Board Support.

Fiducial

Monitoring

This parameter enables and disables the intelligent fiducial monitoring feature,

options are:

Smart; Normal

The default is Normal.

If smart is selected, a set levels menu bar option is available.

Set

Levels

Next Previous Incr. Decr. Exit

On pressing the Set Levels key, a window opens as follows:

The Next and Previous keys move the cursor between the three parameters.

The Incr. and Decr. keys increase and decrease the value of the top two

parameters and turn the Automatic Retry On and Off.

The Exit key closes the window and returns to the set preferences window.

The range of values for the three parameters are as follows:

Score Warning Level:

Min 0

Max 500

Var’n Warning Level:

Min 0

Max 500

Automatic Retry:

Off; On

Score Warning

Level

During fiducial set up the score achieved after training each fiducial is analyzed.

If the score fails to achieve the accept score by more than Score Warning Level,

an instruction box appears recommending the operator check video settings,

fiducial parameters etc.

Var’n Warning

Level

While the machine is running, the score for every fiducial located is monitored.

If for a given fiducial, the score from one fiducial to the next varies by more than

the Variation Warning Level, but does not fall below the minimum accept score,

a message window is displayed, warning that the score of the screen/board

fiducial is fluctuating. Fiducial relearning is advised if the problem persists.

Software Version 6 User Manual 2.15

SET PREFERENCES

PREFERENCES

SMART FIDUCIAL MONITORING

SCORE WARNING LEVEL

VAR'N WARNING LEVEL

AUTOMATIC RETRY

500

OFF

Fiducial Search The parameter enables an auto search to be selected if a screen fiducial or board

fiducial are not found. The feature also enables a machine to run a product setup

on another machine, options are:

Custom; Disabled

The default is Disabled.

Setup If Custom is selected, an Adjust option becomes available on the menu bar:

Adjust Next Previous Incr. Decr. Exit

On selecting Adjust from the menu, a Fiducial Search Strategy window opens:

The menu bar changes to:

Next Previous Incr. Decr. Exit

The Next and Previous keys move the cursor between the two parameters.

The Incr. and Decr. keys change the value of the highlighted parameter.

The Exit key returns to the set preferences menu.

Autosearch This parameter sets whether an automatic search can be selected following a

Fiducial Not Found Error Message. The options are:

1st Board; All Boards

The option Auto Search (F2) is added to the menu bar as follows:

Retry Auto

Fiducial

Setup

Step

Reset

Abort

Depending on the setting, the option Auto Search (F2) is available for the 1st

board or all boards of a batch, following a Fiducial Not Found Error Message.

2.16 User Manual Software Version 6

SET PREFERENCES

PREFERENCES

Fiducial Search Strategy

AUTOSEARCH

WINDOW SIZE

All Boards

16 mm
