HOST COMMUNICATIONS

COMMS PROTOCOL OPTIONS

GEM This configuration implements the SMEMA standard for communications for

Surface Mount Equipment. GEM (Generic Equipment Model) is a standard

sub-set of the SECSII protocol. GEM is specifically designed for implementing

equipment automation in a production environment.

In this configuration, a host computer running GEM compatible software talks to

the machine via a Network cable.

If the Host is a PC, DEK’s Off-line editor software can be used to modify

product files. The Event Log can be read by a text editor. The flexibility of the

GEM interface allows data collection to be customized to meet the users

requirements.

Net_Files This configuration allows users to redirect files away from the machines local

hard drive to a remote directory on a file server. The machine is configured to

access a ‘product’ directory for a product file and a ‘data’ directory for output

data files.

At the machine when a product file is loaded it is read from the ‘product’

directory on the network file server. When it is saved it is saved to the ‘product’

directory on the file server. Files cannot be read from the printer or sent to the

printer across the network.

Once the files are present on the server, they can be accessed from a networked

PC without interfering with the machine.

At a networked PC, DEK’s Off-line Editor software can be used to modify

product files. QC-Calc software can be used to access SPC data in the

‘READINGS.DEK’ file. The Event Log can be read with a text editor.

For details of Comms Protocol Selection see the next section.

Software Version 6 User Manual 3.1

HOST COMMUNICATIONS

COMMS PROTOCOL OPTIONS

Selecting Comms

Protocol Options

The Comms Protocol Set Preference SECS, GEM, and NET_FILE options each

display additional menu parameters if they are selected in the Set Preferences

window.

On selecting GEM the following menu bar is displayed:

Enable

Comms

Next Previous Incr. Decr. Exit

On selecting NET_FILE the following menu bar is displayed:

Enable

Comms

Edit

Comms

Next Previous Incr. Decr. Exit

If the Enable Comms key is pressed the following menu bar is displayed:

Confirm Exit

The user is given the option to Confirm or Exit their selection.

The NET_FILE option may cause a further window to appear requesting the

Network Password.

3.2 User Manual Software Version 6

HOST COMMUNICATIONS

COMMS PROTOCOL OPTIONS

Editing NET_FILE

Comms Options

The NET_FILE comms editing window allows the user to change IP addresses,

user ID, file paths etc.

To enter the Edit Comms window from the set preferences window, select

NET_FILE from the Comms Protocol set preference and press the Edit Comms

menu bar option.

The Edit Comms window appears as follows:

To edit the Edit Comms window the following menu bar appears:

Edit Next Previous Left Right Exit

The Next and Previous keys are used to move the cursor up and down the

current column.

The Left and Right keys move the cursor between the two parameter columns.

The Edit keys makes the parameter under the cursor editable. When editing a

parameter the cursor keys and the delete keys can be used as well as the normal

alphanumeric keys. While editing a parameter (the cursor is still flashing),

pressing the Exit key finishes the current parameters editing.

The Exit key is used to leave the Edit Comms window.

Software Version 6 User Manual 3.3

HOST COMMUNICATIONS

COMMS PROTOCOL OPTIONS

Remote Drive

User ID

Products Path

Data Path

Auto Login

Local Copies

Reconnect Period

Timeout

DISABLED

Network Parameters
