HOST COMMS The machine provides the user with access to certain Host Comms options without accessing the maintenance function. The user is able to send and receive messages to and from the host computer via the Terminal …
Write Stall 7 This limits the amount of time that the SDR driver waits for TCP/IP to accept
data. If the time is exceeded the TCP/IP link is terminated.
Start This statement automatically enables the port when the printer starts up.
Device 0: This defines the printer as device 0.
Device ID 0x109 This allocates an ID to Device 0 (the printer). it is specified as a hexadecimal
number. The default is 0x109 (265 decimal).
Port 0 This defines the port that device 0 uses. In this case Port 0. This refers to the
configuration data previously defined for port 0 above.
Start This statement automatically enables the device when the printer starts up.
Software Version 6 User Manual 3.7
HOST COMMUNICATIONS
IP ADDRESS CONFIGURATION
HOST COMMS The machine provides the user with access to certain Host Comms options
without accessing the maintenance function. The user is able to send and receive
messages to and from the host computer via the Terminal Services option,
upload product data files to the host computer, download product data files from
the host computer and alter the equipment control level.
WARNING
HOST COMMUNICATIONS. BE AWARE THAT IF THE MACHINE
SAFETY LOCKS ARE DEFEATED WHILST HOST
COMMUNICATIONS ARE ACTIVE, A DANGER EXISTS WHEREBY
MACHINE PARTS MAY MOVE UNEXPECTEDLY.
Terminal Services
Message From
GEM Host
When a message is sent to the machine from the Host, the following window is
displayed:
Select Ack Message to acknowledge the message and close the message
window.
Ack
Message
Accessing Terminal
Services
To send and view messages to and from the Host proceed as follows:
1. Select Host Comms.
Log
On
Host
Comms
Clear
Batch
Batch
Limit
Perform
Display
Event
Display
System
Disable
Exit
2. Select Terminal Services.
Terminal
Services
Transfer
To Host
Transfer
To Equip
On-Line Off-Line Local/
Remote
Exit
3.8 User Manual Software Version 6
HOST COMMUNICATIONS
HOST COMMS
Message From GEM Host
Testing host message passing
Message Time: 12:27:56
The terminal services message windows are displayed as follows:
The most recent message from the Host is displayed in the upper window.
If a new message arrives while the window is open, the upper window displays
the new message and the Ack Message key is visible. Select Ack Message to
acknowledge to the Host that the message has been received.
Ack
Message
3. To send a message to the Host, type the message using the keyboard, the
message appears in the lower window.
4. Select Send Message to send the message in the lower window to the Host.
Send
Message
Exit
5. Select Exit.
Exit
Software Version 6 User Manual 3.9
HOST COMMUNICATIONS
HOST COMMS
Message From GEM Host
Message Time: 12:27:56
Message to GEM Host Message Time: 12:27:56
_
