Upload a Product Data File To upload a product data file from the Host proceed as follows: 1. Select Host Comms . Log On Host Comms Clear Batch Batch Limit Perform Display Event Display System Disable Exit The Host Commu…
The terminal services message windows are displayed as follows:
The most recent message from the Host is displayed in the upper window.
If a new message arrives while the window is open, the upper window displays
the new message and the Ack Message key is visible. Select Ack Message to
acknowledge to the Host that the message has been received.
Ack
Message
3. To send a message to the Host, type the message using the keyboard, the
message appears in the lower window.
4. Select Send Message to send the message in the lower window to the Host.
Send
Message
Exit
5. Select Exit.
Exit
Software Version 6 User Manual 3.9
HOST COMMUNICATIONS
HOST COMMS
Message From GEM Host
Message Time: 12:27:56
Message to GEM Host Message Time: 12:27:56
_
Upload a
Product Data File
To upload a product data file from the Host proceed as follows:
1. Select Host Comms.
Log
On
Host
Comms
Clear
Batch
Batch
Limit
Perform
Display
Event
Display
System
Disable
Exit
The Host Communications window is displayed as follows:
2. Select Transfer To Host.
Terminal
Services
Transfer
To Host
Transfer
To Equip
On-Line Off-Line Local/
Remote
Exit
The Upload Data File window is displayed as follows:
3. Using the Left, Right, Up and Down keys, highlight the required data file.
Upload
File
Left Right Up Down
Exit
3.10 User Manual Software Version 6
HOST COMMUNICATIONS
HOST COMMS
Host Communications
Communications Protocol
Communications:
Equipment Control
On-Line Control
GEM
Enabled-Communications
On-Line
Remote
Upload Data File
CALIBRA
CIRCLE
CROSS
DEFAULT
DEK04
HASH
NEWFILE
NEWFILE2
ODDFILE
SQUARE
TEST
TEST2
TEST3
TRIANGL
4. Select Upload File, the chosen product data file is transferred to the Host.
Upload
File
Left Right Up Down Exit
5. Select Exit.
Upload
File
Left Right Up Down
Exit
6. Select Exit.
Terminal
Services
Transfer
To Host
Transfer
To Equip
On-Line Off-Line Local/
Remote
Exit
Download a
Product Data File
To download a product data file from the Host proceed as follows:
1. Select Host Comms.
Log
On
Host
Comms
Clear
Batch
Batch
Limit
Perform
Display
Event
Display
System
Disable
Exit
The Host Communications window is displayed as follows:
2. Select Transfer To Equip.
Terminal
Services
Transfer
To Host
Transfer
To Equip
On-Line Off-Line Local/
Remote
Exit
Software Version 6 User Manual 3.11
HOST COMMUNICATIONS
HOST COMMS
Host Communications
Communications Protocol
Communications:
Equipment Control
On-Line Control
GEM
Enabled-Communications
On-Line
Remote
