4. Select Upload File , the chosen product data file is transferred to the Host. Upload File Left Right Up Down Exit 5. Select Exit . Upload File Left Right Up Down Exit 6. Select Exit . Terminal Services Transfer To Hos…

100%1 / 378
Upload a
Product Data File
To upload a product data file from the Host proceed as follows:
1. Select Host Comms.
Log
On
Host
Comms
Clear
Batch
Batch
Limit
Perform
Display
Event
Display
System
Disable
Exit
The Host Communications window is displayed as follows:
2. Select Transfer To Host.
Terminal
Services
Transfer
To Host
Transfer
To Equip
On-Line Off-Line Local/
Remote
Exit
The Upload Data File window is displayed as follows:
3. Using the Left, Right, Up and Down keys, highlight the required data file.
Upload
File
Left Right Up Down
Exit
3.10 User Manual Software Version 6
HOST COMMUNICATIONS
HOST COMMS
Host Communications
Communications Protocol
Communications:
Equipment Control
On-Line Control
GEM
Enabled-Communications
On-Line
Remote
Upload Data File
CALIBRA
CIRCLE
CROSS
DEFAULT
DEK04
HASH
NEWFILE
NEWFILE2
ODDFILE
SQUARE
TEST
TEST2
TEST3
TRIANGL
4. Select Upload File, the chosen product data file is transferred to the Host.
Upload
File
Left Right Up Down Exit
5. Select Exit.
Upload
File
Left Right Up Down
Exit
6. Select Exit.
Terminal
Services
Transfer
To Host
Transfer
To Equip
On-Line Off-Line Local/
Remote
Exit
Download a
Product Data File
To download a product data file from the Host proceed as follows:
1. Select Host Comms.
Log
On
Host
Comms
Clear
Batch
Batch
Limit
Perform
Display
Event
Display
System
Disable
Exit
The Host Communications window is displayed as follows:
2. Select Transfer To Equip.
Terminal
Services
Transfer
To Host
Transfer
To Equip
On-Line Off-Line Local/
Remote
Exit
Software Version 6 User Manual 3.11
HOST COMMUNICATIONS
HOST COMMS
Host Communications
Communications Protocol
Communications:
Equipment Control
On-Line Control
GEM
Enabled-Communications
On-Line
Remote
The Download Data window is displayed as follows:
3. Enter the name of the required product data file to download from the Host,
via the keyboard.
4. Select Download, the chosen product data file is transferred from the Host.
Download
Exit
5. Select Exit.
Terminal
Services
Transfer
To Host
Transfer
To Equip
On-Line Off-Line Local/
Remote
Exit
Equipment Control
Level
To change the equipment control level proceed as follows:
1. Select Host Comms.
Log
On
Host
Comms
Clear
Batch
Batch
Limit
Perform
Display
Event
Display
System
Disable
Exit
The Host Communications window is displayed as follows:
3.12 User Manual Software Version 6
HOST COMMUNICATIONS
HOST COMMS
Download Data
File Name:
------------------------------
Host Communications
Communications Protocol
Communications:
Equipment Control
On-Line Control
GEM
Enabled-Communications
On-Line
Remote
