ERROR MESSAGES
INTRODUCTION If for any reason the machine does not complete a particular sequence in the time
allowed for in software, an error condition arises. The relevant error message is
displayed on the main control screen.
Machine Errors are detected by sensors specifically designed for checking
correct machine status (System Power, Pneumatic Power, etc.) or by functions
failing to achieve their correct operation. These latter errors are either detected
by a limit sensor being operated or by setting a time limit for their completion.
The time limits are set so they are 1.5 times the longest possible time taken for
that particular operation, after which, if not completed, an error is reported on the
main control screen.
When an error occurs the relevant message is displayed on the main control
screen. The displayed error message is accompanied by information regarding
the possible causes and the corrective action to be taken.
The Tricolour beacon changes to red and records the error in the Event Log file.
Software Version 6 User Manual 4.1
ERROR MESSAGES
INTRODUCTION
ERROR RECOVERY
When an error message is displayed the following options maybe available to
recover the machine:
Abort Pressing this option re-initializes the entire printer, ejecting any product that may
be in the printer and returning to the main control page.
Retry Selecting this option re-checks the error condition and if clear continues the print
cycle.
Recover Pressing this option attempts to continue with any cycle that is in operation. This
function sets modules (paste dispenser, print carriage, etc.) to their home
position and ejects the board that is currently in the printer without re-initializing
the machine. This option should be the first to be operated if there is an error
reported.
Diagnostics This option enables the diagnostics to be entered immediately, normally by a
technician, for more in-depth investigation of the problem.
Open Cover This option allows the operator to select Change Screen to gain access to the
tooling area of the machine.
Continue When this option is available, selecting the continue key clears the error message
and continue with the cycle that is in operation.
Fiducial Setup When this option is available, selecting the Fiducial Setup key allows the user to
relearn the reported ‘Not Found’ fiducial.
Auto Search When this option is available, selecting the Auto Search key instigates a search
within the selected window size to locate the ‘Not Found’ fiducial.
Search Step When this option is available, selecting the Search Step key moves the camera
the first step in a search procedure designed to locate the ‘Not Found’ fiducial.
Further selection of the key moves the camera to the second step etc. Once the
fiducial is visible in the region of interest, the Retry key can be selected to
capture the fiducial.
Search Reset When this option is available, selecting the Search Reset key returns the camera
to its original position, before the Search Step key was selected. This is the
position from which the ‘Not Found’ fiducial was reported.
4.2 User Manual Software Version 6
ERROR MESSAGES
ERROR RECOVERY
ERROR MESSAGE LISTING
Error Message Interpretation
Alignment Out of Range This indicates that the actuator positions required to achieve
a satisfactory alignment are not attainable.
Alignment Close to
Limit/Out of Range
Actuator limit exceeded.
AutoFlex Timed Out This error reports that with AutoFlex tooling on high power
and the tooling pins up, the process time of 5 minutes has
been exceeded. When this message is displayed the power
is also switched to low.
Board Detected At Board
Stop, Print Terminated.
With the machine running in any mode, this error reports
that the board stop sensor has been activated out of
sequence.
Possible causes are:
Board already loaded into the machine.
Sensor is detecting tooling.
Sensor is faulty.
Board Fiducial Not Found This error reports that the vision system has been unable to
locate the board fiducial.
Board Not Over Input
Sensor
This error reports a machine has started without a board on
the rails. The user has ignored the message to place a board
on the rails and selects continue on the machine.
Board On Rails, Remove
and Continue
This error reports that a board has been sensed on the rails
during one of the following operations:
Initialization
Loading a new board file
Entering the rail system in diagnostics.
Board Stop Not Lowered This error reports that the board stop is up and has not
lowered within the time-out period of 3 seconds. The
possible causes are: Board stop sensor - enter Diagnostics
and check the sensor changes state.
Air pressure failure to the board stop.
Board Stop Not Retracted This error reports that the board stop is down and has not
retracted within the time-out period of 3 seconds. A
possible cause is:
Board stop sensor - enter Diagnostics, Digital Inputs and
check the sensor changes state.
Board Stop Stuck This error reports that the board stop, which is housed in
the camera assembly has failed to lower or retract.
Board Stuck in Rails This error reports that the board has failed to either reach
the board stop or exit the machine after being printed.
Camera X Axis Error This error reports that the camera carriage has failed to
reach its home position in the X axis.
Camera Y Axis Error This error reports that the camera carriage has failed to
reach its home position in the Y axis.
Command Timed Out
(Belt Motors)
This error reports if a board on the belt fails to move over
the board at left/right sensor within the time period.
Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Software Version 6 User Manual 4.3
ERROR MESSAGES
ERROR MESSAGE LISTING
