ERROR MESSAGE LISTING
Error Message Interpretation
Alignment Out of Range This indicates that the actuator positions required to achieve
a satisfactory alignment are not attainable.
Alignment Close to
Limit/Out of Range
Actuator limit exceeded.
AutoFlex Timed Out This error reports that with AutoFlex tooling on high power
and the tooling pins up, the process time of 5 minutes has
been exceeded. When this message is displayed the power
is also switched to low.
Board Detected At Board
Stop, Print Terminated.
With the machine running in any mode, this error reports
that the board stop sensor has been activated out of
sequence.
Possible causes are:
Board already loaded into the machine.
Sensor is detecting tooling.
Sensor is faulty.
Board Fiducial Not Found This error reports that the vision system has been unable to
locate the board fiducial.
Board Not Over Input
Sensor
This error reports a machine has started without a board on
the rails. The user has ignored the message to place a board
on the rails and selects continue on the machine.
Board On Rails, Remove
and Continue
This error reports that a board has been sensed on the rails
during one of the following operations:
Initialization
Loading a new board file
Entering the rail system in diagnostics.
Board Stop Not Lowered This error reports that the board stop is up and has not
lowered within the time-out period of 3 seconds. The
possible causes are: Board stop sensor - enter Diagnostics
and check the sensor changes state.
Air pressure failure to the board stop.
Board Stop Not Retracted This error reports that the board stop is down and has not
retracted within the time-out period of 3 seconds. A
possible cause is:
Board stop sensor - enter Diagnostics, Digital Inputs and
check the sensor changes state.
Board Stop Stuck This error reports that the board stop, which is housed in
the camera assembly has failed to lower or retract.
Board Stuck in Rails This error reports that the board has failed to either reach
the board stop or exit the machine after being printed.
Camera X Axis Error This error reports that the camera carriage has failed to
reach its home position in the X axis.
Camera Y Axis Error This error reports that the camera carriage has failed to
reach its home position in the Y axis.
Command Timed Out
(Belt Motors)
This error reports if a board on the belt fails to move over
the board at left/right sensor within the time period.
Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Software Version 6 User Manual 4.3
ERROR MESSAGES
ERROR MESSAGE LISTING
Error Message Interpretation
Command Timed Out
(Camera Axes)
This error reports that the camera has failed to move to the
demanded position within the time period. This error
applies to both the X and Y camera axis. Possible causes
are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Command Timed Out
(Paste Dispense Carriage)
This error reports that the paste dispense carriage has failed
to move to the demanded position within the time period.
Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Command Timed Out
(Print Carriage)
This error reports that the print carriage has failed to move
to the demanded position within the time period. Possible
causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Command Timed Out
(Proflow)
This error reports that the proflow unit has failed to move to
the demanded position within the time period. Possible
causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Command Timed Out
(Rail System)
This error reports that the moving rail has failed to move to
the demanded position within the time period. Possible
causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Command Timed Out
(Screen Actuators)
This error reports that the actuator has failed to move to the
demanded position within the time period. Possible causes
are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Command Timed Out
(Front/Rear Squeegee)
This error reports that the front/rear squeegee has failed to
move to the demanded position within the time period.
Possible causes are:
Home sensor fault, if occurring during initialization.
Motor fault, if occurring during initialization.
Motor not running.
NextMove card faulty.
Downline Board Transfer
Fault
This error reports that the time the downline interface has
waited for a board has exceeded the time-out.
Downline Machine Not
Available
This error reports that the downline machine is unavailable
to accept the next board.
Event File Open Error This error reports that there was a problem opening the
event log backup file.
4.4 User Manual Software Version 6
ERROR MESSAGES
ERROR MESSAGE LISTING
Error Message Interpretation
Failed to Determine
Tooling Deviation
This error reports that while monitoring the tooling
deviation, the number of samples (pressure variations)
during the print stroke was less than 2 or the minimum
value was zero. This error message is only valid where
tooling deviation is authorized and enabled.
Check tooling support is sufficient.
Check underside components are clear of tooling.
Front Squeegee Error This error reports that the front squeegee has failed to reach
its fully up position.
Front Squeegee Pressure
Error
When this error is detected a new window displays the set
pressure reading and the actual pressure reading.
File Error This message appears if there is an error writing or reading
a 265 file.
Have All Tooling Pins
Been Removed ?
This message appears for the user to confirm that all
magnetic tooling pins have been removed, before setting up
the machine for a new board file that uses AutoFlex tooling.
Invalid Calibration Data.
Recalibrate ProFlow
Heights
This error reports that the ProFlow calibration data is
corrupt or invalid.
Invalid Calibration Data.
Recalibrate Squeegee
Heights
This error reports that the squeegee calibration data is
corrupt or invalid.
Lid Bolt Fault This indicates that the lid bolt has failed to either open or
close.
No Paste Knead Cycles
Selected
This error reports when Knead Paste is selected on main
menu page and Knead Deposits in Set Prefs is selected to 0
cycles.
Paste Carriage Error This error reports that the paste carriage has failed to reach
its home position.
Paste Cartridge Tilt Error This error reports that the paste cartridge mechanism has
failed to either make its up or down limit switches.
Pneumatic Power Down This error message reports that the pneumatic supply is
either too low or has been disconnected.
Position Error
(Camera)
This error reports that the cameras actual position is not
within the tolerance of 1% of the designated position.
Position Error
(Print Carriage)
This error reports the print carriage actual position is not
within tolerance of its designated position.
Position Error
(Rising Table)
This error reports that the rising table has failed to reach its
home position.
Print Carriage Error This error reports that the print carriage has failed to move.
Proflow Downstop At
Limit
This error reports when the downstop reaches set limits
whilst using the jog buttons in Diagnostics, Drive
Downstop Using Jog Buttons.
Proflow at Movement
Limit
This error reports when the proflow reaches set limits
whilst using jog buttons in Diagnostics, Drive System
Using Jog Buttons.
Software Version 6 User Manual 4.5
ERROR MESSAGES
ERROR MESSAGE LISTING
