DIAGNOSTICS
INTRODUCTION The diagnostic function is an aid to the user to allow individual access and
control of motors and modules. It allows the user to control the sequence of the
machine so that a particular module can be exercised.
Run Open
Cover
Paste
Load
Clean
Screen
Adjust Setup Monitor
Maint.
To enter the diagnostic mode press the Maint button and the menu bar changes
displaying the Diagnostic option.
Calibrat
Pressure
Calibrat
Offset
Calibrat
Vision
House
Keeping
Set
Prefs
Diagnost
Test
cycles
Exit
Press the Diagnostic button and the message ‘System Power Down’ is
displayed on the screen, pressing the System button, enters into the main
diagnostic menu. If a password exists a window displays the message
‘Diagnostic Password’. If the password is incorrect control displays the
message ‘Invalid password entered’ and returns to the previous menu. If the
correct password is entered or no password exists a pop up window displays the
following:
Software Version 6 User Manual 5.1
DIAGNOSTICS
INTRODUCTION
Mo
d
u
l
eD
i
agnost
i
cPage
System
Print Carriage
ProFlow / Squeegee
Camera Axes
Rail System
Paste Dispense System
Screen Alignment
Screen Change
Screen Cleaner
Rising Table
MIU
Autoflex Tooling
The menu bar changes displaying the following:
Select
Module
Next Previous Exit
Next / Previous keys move the highlight bar up and down the list of diagnostic
modules.
Select Module key opens a new window displaying the diagnostic functions
available for the selected module.
Exit returns operation to the start of initialization.
NOTE
Before any diagnostic function is used in any of the modules they must be homed
first or they are not able to initiate a command.
5.2 User Manual Software Version 6
