STAGE 1 For machines with the remote board stop option, ensure that the machine is
correctly configured for the intended product. Carry out the appropriate one of
the following procedures:
•
Camera to Remote Board Stop - LHS Configuration
•
Camera to Remote Board Stop - RHS Configuration
•
Remote Board Stop - LHS to RHS Configuration
•
Remote Board Stop - RHS to LHS Configuration
•
Remote Board Stop - Same Side Configuration
•
Remote Board Stop to Camera Board Stop
See Technical Reference Manual, Rising Table Module Chapter, Replacement
Procedures, for the first five procedures and Technical Reference Manual,
Camera and Vision System Module Chapter, Replacement Procedures for the
Remote Board Stop to Camera Board Stop procedure.
Power Up and
Log On
1. Turn the mains isolator switch to On.
2. When the message ‘Press SYSTEM Switch To Initialize Printer or Select
Diagnostics or Load Data’ is displayed in the message prompt bar, either:
a) Select Load Data (F2) if the loaded product is unknown or needs to be
changed.
b) Go to Step 5 if the loaded product file is known to be the correct one.
Load
Data
Diagnost
The following Load Data File window is displayed:
1.2 User Manual Software Version 6
MACHINE PROGRAMMING
STAGE 1
3. Use Left, Right, Up or Down function keys (F4-F7) to highlight the
required file.
Load Rebuild
List
Left Right Up Down
Exit
4. Press Load (F1).
Load
Rebuild
List
Left Right Up Down Exit
5. Initialize the machine by pressing the System button.
The selected file is now displayed on the status page.
The operator can change the language used in the display menus.
To select a different language continue with Step 6. If the correct language is
loaded go to Step 12.
6. Select Setup (F6).
Run Open
Cover
Paste
Load
Clean
Screen
Adjust
Setup
Monitor Maint.
7. Select Change Language (F7).
Mode Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
8. A list of installed languages is displayed. Select Up (F5), or Down (F6) until
the desired language is highlighted.
Software Version 6 User Manual 1.3
MACHINE PROGRAMMING
STAGE 1
9. Select Load (F1).
Load
Up Down Exit
The message ‘Loading Language...’ is displayed. A delay of approximately 20
seconds take place and all displayed text is changed to the selected language.
The message ‘Language Loaded...’ is displayed.
10. Select Exit (F8).
Load Up Down
Exit
11. Select Exit (F8).
Mode Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
12. Select Monitor (F7).
Run Open
Cover
Paste
Load
Clean
Screen
Adjust Setup
Monitor
Maint.
13. Select Log On (F1).
Log
On
Host
Comms
Clear
Batch
Batch
Limit
Perform
Display
Event
Display
System
Disable
Exit
The Operator Log On window is displayed:
Using the keyboard, enter the operator’s name/ID and press Enter on the
keyboard, the operator’s name/ID appear on the status page.
