PASTE DISPENSE SYSTEM Selecting this diagnostics module opens the following window: The menu bar changes to the following: Run Diagnost Next Previous Exit Next / Previous keys move the highlight bar up and down the list …
Board at Stop This diagnostic function continuously displays the status of the board at stop
sensor.
Board at Left This diagnostic function continuously displays the status of the left board sensor.
On is displayed if a board is detected on the rails at the left of the machine.
Board at Right This diagnostic function continuously displays the status of the right board
sensor. On is displayed if a board is detected on the rails at the right of the
machine.
Cycle Count This diagnostic function displays the amount of cycles done and the amount of
cycles to go to complete the cycle count.
5.20 User Manual Software Version 6
DIAGNOSTICS
RAIL SYSTEM
PASTE DISPENSE SYSTEM
Selecting this diagnostics module opens the following window:
The menu bar changes to the following:
Run
Diagnost
Next Previous Exit
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
Carriage Home Selecting this diagnostic function drives the paste dispense carriage left to its
home position, as determined by its home sensor.
Drive Carriage to
Start Position
Selecting this diagnostic function drives the paste dispense carriage to the
position set by the paste start parameter.
Drive Carriage to
End Position
Selecting this diagnostic function drives the paste dispense carriage to the
position set by the paste stop parameter.
Drive Cartridge
Down
Selecting this diagnostic function drives the cartridge tilt motor down until the
cartridge away (down) sensor is detected.
Drive Cartridge Up Selecting this diagnostic function drives the cartridge tilt motor up until the
cartridge home (up) sensor is detected.
Toggle Paste
Dispense
Selecting this diagnostic function alternately applies and removes the air
pressure to the paste dispense cartridge, displaying On when air pressure is
applied and Off when air pressure is removed.
Software Version 6 User Manual 5.21
DIAGNOSTICS
PASTE DISPENSE SYSTEM
Paste Cartridge Empty
Cartridge in Down Position
Cartridge in Up Position
ON
ON
OFF
OFF
Carriage Home
Drive Carriage To Start Position
Drive Carriage To End Position
Drive Cartridge Down
Drive Cartridge Up
Toggle Paste Dispense
Paste D
i
spense System D
i
agnost
i
cs
Paste Cartridge
Empty
This diagnostic function continuously displays the status of the cartridge empty
sensor.
Cartridge in Down
Position
This diagnostic function continuously displays the status of the cartridge away
(down) sensor.
Cartridge in Up
Position
This diagnostic function continuously displays the status of the cartridge home
(up) sensor.
5.22 User Manual Software Version 6
DIAGNOSTICS
PASTE DISPENSE SYSTEM
