Toggle Pinch Valve Selecting this diagnostic function alternately energizes and de-energizes the solvent valve, displaying On when the solvent valve is energized and Off when the solvent valve is de-energized. Toggle Pap…

100%1 / 378
SCREEN CLEANER
Selecting this diagnostics module opens the following window:
NOTE
Toggle Paper Feed and Cleaner Paper Low/Advance are not present when the
Vortex under screen cleaner is fitted.
The menu bar changes to the following:
Run
Diagnost
Adjust Next Previous Exit
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
Adjust opens the following window:
The menu bar changes to the following:
Incr. Decr. Exit
Incr. / Decr. keys change the value of the cycle count.
Exit returns operation to the screen cleaner diagnostics page.
Toggle Dry Wipe
Blade
Selecting this diagnostic function raises and lowers the cleaner body assembly,
displaying On when the cleaner body assembly is raised and Off when the
cleaner body assembly is lowered.
5.26 User Manual Software Version 6
DIAGNOSTICS
SCREEN CLEANER
Screen C
l
eaner D
i
agnost
i
cs
..more
ON
ON
ON
ON
ON
ON
ON
ON
ON
Cleaner Paper Low/Advance
Cleaner Solvent Low
Pinch Valve Fitted
Toggle Dry Wipe Blade
Toggle Pinch Valve (if fitted)
Toggle Paper Feed
Toggle Vacuum
Toggle Solvent Feed/Tank Press
Toggle Screen Cleaner Home Clamp
Cycle Pinch Valve
Cycle Clean Blade
Cycle Count
Done :-
0, To go :-
50
Cleaner Cycle Parameters
CYCLE COUNT
50.0
Cycles
Toggle Pinch Valve Selecting this diagnostic function alternately energizes and de-energizes the
solvent valve, displaying On when the solvent valve is energized and Off when
the solvent valve is de-energized.
Toggle Paper Feed Selecting this diagnostic function alternately switches the paper feed motor on
and off, displaying its current status. This function is not displayed if the Vortex
under screen cleaner is fitted.
Toggle Vacuum Selecting this diagnostic function alternately switches the vacuum pump on and
off, displaying its current status.
Toggle Solvent
Feed/Tank Pressure
Selecting this diagnostic function alternately energizes and de-energizes the
solvent tank pressure solenoid, displaying On when air pressure is switched to
the tank and Off when air pressure is removed.
Toggle Screen
Cleaner Home
Clamp
Selecting this diagnostic function alternately energizes and de-energizes the
screen cleaner home clamp electromagnet, displaying its status.
Cycle Pinch Valve Selecting this diagnostic function continuously opens and closes the solvent
valve for the number of cycles specified in the cycle count.
Cycle Clean Blade Selecting this diagnostic function continuously raises and lowers the cleaner
body assembly for the number of cycles specified in the cycle count.
Cleaner Paper Low
/Advance
This diagnostic function continuously displays the status of the cleaner paper
low/advance sensor. This function is not displayed if the Vortex under screen
cleaner is fitted.
Cleaner Solvent
Low
This diagnostic function continuously displays the status of the cleaner solvent
low sensor.
Pinch Valve Fitted This diagnostic function continuously displays the status of the solvent valve.
Cycle Count This diagnostic function displays the amount of cycles done and the amount of
cycles to go to complete the cycle count.
Software Version 6 User Manual 5.27
DIAGNOSTICS
SCREEN CLEANER
RISING TABLE Selecting this diagnostics module opens the following window:
The menu bar changes to the following:
Run
Diagnost
Adjust Next Previous Exit
Next / Previous keys move the highlight bar up and down the list of selectable
diagnostic functions.
Run Diagnost activates the diagnostic function, as selected by the highlight bar.
Exit returns operation to the module diagnostics page.
Adjust opens the following window:
The menu bar changes to the following:
Next Previous Incr. Decr. Exit
Next / Previous keys have no function in this application.
Incr. / Decr. keys change the value of the cycle count.
Exit returns operation to the rising table diagnostics page.
Home Rising Table Selecting this diagnostic function drives the rising table down to the home
position, as indicated by its home sensor.
Raise Table to
Vision Height
Selecting this diagnostic function drives the rising table to the height set by the
vision height parameter.
5.28 User Manual Software Version 6
DIAGNOSTICS
RISING TABLE
R
i
s
i
ng Ta
bl
eD
i
agnost
i
cs
Rail Lifted Left
Rail Lifted Right
Table at Home
Cycle Count
ON
OFF
OFF
OFF
OFF
Done :-
0, To go :-
50
Home Rising Table
Raise Table to Vision Height
Raise Table to Print Height
Restore Default Heights
Set Reference Vision Height
Set Reference Print Height
Drive Table using Jog Buttons
Toggle Table Brake
Toggle Vacuum Tooling Valve
Cycle Rising Table
Table Cycle Test Parameters
CYCLE COUNT
50.0
Cycles
