If the Copy Data key is pressed when Image Data is highlighted, the following window is displayed: The menu bar changes to the following: Copy File Left Right Up Down Exit The Copy File key copies the selected product da…
The file names under each item are as follows:
Event Log Test Data SPC Data Config Data Service Data Deviation Data
event.dat atest.dat readings.dek calib.ini service.dat deviate.dat
fiducial.dat config.cfg replen.dat
inspect.dat maint.dat
location.dat config.txt
offset.dat
test.dat
test.log
theta.dat
videoxy.dat
If the Copy Data key is pressed when Product Data is highlighted, the message
‘Do you also want to create a copy of the inspection data?’ is displayed. The
following window is displayed:
The menu bar changes to the following:
Yes No
The Yes key copies the highlighted product data file between the drives as
indicated, with all the inspection data that is associated with it. The message
‘Copying All Files Please Wait’ is displayed.
The No key copies the highlighted product data file between the drives as
indicated, without the inspection data that is associated with it. The message
‘Copying All Files Please Wait’ is displayed.
Software Version 6 User Manual 7.7
HOUSE KEEPING
COPY DATA
Copy Data File
265TEST1
CALIBRA
DEFAULT
Search
265TEST1
Product ID
265TEST1-
If the Copy Data key is pressed when Image Data is highlighted, the following
window is displayed:
The menu bar changes to the following:
Copy
File
Left Right Up Down Exit
The Copy File key copies the selected product data file from the source to the
destination.
The Left and Right keys move the cursor between product file columns (if
displayed).
The Up and Down keys move the cursor between the various product data files.
The Exit key returns to the previous menu.
If the Copy All key is pressed when Product Data is highlighted, the message
‘Do you also want to create a copy of the inspection data associated with
each process program that is to be copied?’ is displayed. The menu bar
changes to the following:
Yes No
The Yes key copies all the product data files between the drives as indicated,
with all the inspection data that is associated with them. The message ‘Copying
All Files Please Wait’ is displayed.
The No key copies all the product data files between the drives as indicated,
without the inspection data that is associated with them. The message ‘Copying
All Files Please Wait’ is displayed.
7.8 User Manual Software Version 6
HOUSE KEEPING
COPY DATA
Copy Data File
Insp0000
Insp0001
Insp0002
Insp0003
Insp0004
Insp0005
DELETE DATA The Delete Data function allows the operator to delete various data types.
On selecting the Delete Data key the following window is displayed:
NOTE
Image Data is available with 2D Inspection only. Deviation Data is only
available on machines with Tooling Monitoring authorized.
The menu bar changes to the following:
Delete
Data
Up Down Exit
The Up and Down keys move the cursor through the data types.
The function of the Delete Data option depends on the type of data selected, the
options are:
Product Data; Event Log; Test Data; SPC Data; Config Data; Service Data;
Deviation Data; Image Data
Product Data If the Delete Data key is pressed when Product Data is highlighted the following
window is displayed:
Software Version 6 User Manual 7.9
HOUSE KEEPING
DELETE DATA
Drive
Delete From: Local Drive
Delete Data
Product Data
Event Log
Test Data
SPC Data
Config Data
Service Data
Deviation Data
Image Data
Delete Data File
265TEST1
CALIBRA
DEFAULT
Search
265TEST1
Product ID
265TEST1-
