5. Using the Next, Previous, Incr. and Decr. keys, edit the current process

parameters for the new product.

Save

Next Previous Incr. Decr.

Exit

6. Press Save.

Save

Next Previous Incr. Decr. Exit

7. When the message ‘Board Data File Saved’ is displayed, press Exit.

Save Next Previous Incr. Decr.

Exit

8. Select Mode until Step appears in mode option of the printer status display.

Mode

Load

Data

Edit

Data

Setup

Squeegee

Change

Screen

Change

Tooling

Change

Language

Exit

If the required screen is already in the printer go to Step 16.

If the screen needs to be changed continue with Step 9.

9. Select Change Screen.

Mode Load

Data

Edit

Data

Setup

Squeegee

Change

Screen

Change

Tooling

Change

Language

Exit

10. When the message ‘Open Front Cover and Remove Screen’ is displayed

lift the printhead cover.

11. Remove the screen from the printer.

12. Fit the new screen into the printer ensuring the correct orientation of the

screen.

13. Lower the printhead cover.

14. Press the System button on the control console.

15. Select Change Screen.

Mode Load

Data

Edit

Data

Setup

Squeegee

Change

Screen

Change

Tooling

Change

Language

Exit

16. Select Exit.

Mode Load

Data

Edit

Data

Setup

Squeegee

Change

Screen

Change

Tooling

Change

Language

Exit

8.16 User Manual Software Version 6

2Di INSPECTION

2Di SETUP

17. Select Run.

Run

Open

Cover

Paste

Load

Clean

Screen

Adjust Setup Monitor Maint.

18. If the screen has not been changed the message ‘Screen has not been

changed for this product’ is displayed, select Use Screen to continue.

19. Select Auto Board.

Auto

Board

Manual

Board

Knead

Paste

Exit

20. The message ‘Load board’ is displayed. Load board, select Confirm when

the board is loaded.

Confirm

Exit

21. Setup the board and screen fiducials.

22. Select Inspect Setup. If this option is unavailable, check set prefs for 2D

Inspection enabled.

Step Open

Cover

Inspect

Setup

Single Exit

NOTE

The windows in this procedure show the parameters and options available with

both screen and board inspect type set to advanced. If screen or board inspect

type is set to basic or none, certain parameters and options are not displayed.

CAUTION

FIDUCIAL POSITION. If during the print cycle, the position of board

fiducials are changed, the position of previous inspection sites (if any) may

be affected. Small changes are automatically compensated for, however

large changes, ie more than 3mm, require sites to be repositioned.

Software Version 6 User Manual 8.17

2Di INSPECTION

2Di SETUP

2D INSPECT RATE

STENCIL INSPECT TYPE

BOARD INSPECT TYPE

PRE-IMAGE

MIN SITES/CYCLE

WARNING LIMIT

BLOCKAGE ACTION

BLOCKAGE CLEAN

SMEAR ACTION

SMEAR CLEAN

LOW PASTE ACTION

INSPECT AFTER CLEAN

POST PRINT ALIGNMENT

No. SITES

ADVANCED

EVERY

MANUAL ACTION

MODE 1

MANUAL ACTION

MODE 2

RE-PRINT

ENABLED

PERFORMED

Global Inspect Parameters

SITE NAME

SITE PRIORITY

STENCIL INSPECT TYPE

BOARD INSPECT TYPE

SITE ALIGNMENT

LIMIT SITE I.D.

PASTE SCALING

SITE X COORD

SITE Y COORD

SITE WIDTH

SITE HEIGHT

QFP 1

GENERAL

ADVANCED

X AND Y

FINE

1.00

84.5 mm

89.5mm

4.00 mm

Site Parameters

Edit Global 1. Select Edit Global.

Edit

Global

Edit

Limits

Delete

Site

Edit

Site

Inspect

Site

Exit

NOTE

Delete site is only available if at least one site exists already.

Next site and previous site are only available if at least two sites exist already.

2. Enter the parameter values below using the Next, Previous, Incr. and Decr.

keys.

Limit

Options

Next Previous Incr. Decr.

Exit

• Pre-image to Every

• Min Sites to 10

•

Warning Limit to 20, this can be reduced later in ‘adjust inspect’.

•

Blockage Action to Manual, this can be changed later in ‘adjust inspect’.

•

Smear Action to Manual, this can be changed later in ‘adjust inspect’.

A definition of all 2Di parameters and their values is given at the end of this

chapter.

On completion of successful setup, parameters can be adjusted to suit the

product.

3. Select Limit Options.

Limit

Options

Next Previous Incr. Decr. Exit

8.18 User Manual Software Version 6

2Di INSPECTION

2Di SETUP

Advanced

Every

Manual

Mode 1

Manual

Mode 2

Manual

Enabled

Performed

Stencil Inspect Type

Board Inspect Type

Pre-image

Min. Sites/Cycle

Warning Limit

Blockage Action

Blockage Clean

Smear Action

Smear Clean

Low Paste Action

Inspect After Clean

Post Print Alignment

Edit Global Parameters
