4. Select Save Limits . The message ‘Saving Fiducial Data - Please Wait Board data file saved’ is displayed. Save Limits Next Previous Incr. Decr. Exit 5. Select Exit . Save Limits Next Previous Incr. Decr. Exit 6. Selec…
Limit sets list the different sets of limit parameters that are available, initially
only default is available. Limit parameters list the current limits for the
highlighted limit set.
2. At this point either:
a) Add limits to create a new limit set, continue with Add Limits below.
or
b) Edit limits to edit an existing limit set, go to Edit Limits over the page.
NOTE
It is recommended that during setup, parameters are set at a level that no alarms
occur (coarse). Once the inspection is correctly setup, the parameters can be
tightened during production in ‘adjust inspect’.
Add Limits 1. Select Add Limits.
Add
Limits
Edit
Limits
Next
Limit
Previous
Limit
Exit
NOTE
Next limit and previous limit are only available if at least one limit, plus the
default, exist already.
2. Use the keyboard to enter the ID of the new limit set and press Enter.
NOTE
Limit ID may be any name up to 20 characters in length including spaces.
3. Enter parameters using the Next, Previous, Incr. and Decr. keys. A coarse
set of values is shown above.
Save
Limits
Next Previous Incr. Decr.
Exit
8.20 User Manual Software Version 6
2Di INSPECTION
2Di SETUP
COARSE
20
25
1.00 sq mm
1.50 sq mm
70
65
0.200 mm
0.250 mm
0.015 mm
0.010 mm
80
70
Limit Set ID
BlockageWarning
BlockageAlarm
SmearWarning
SmearAlarm
PasteWarning
PasteAlarm
AlignWarning
AlignAlarm
BridgeWarning
BridgeAlarm
VolumeWarning
VolumeAlarm
Edit Limit Parameters
4. Select Save Limits.
The message ‘Saving Fiducial Data - Please Wait
Board data file saved’ is displayed.
Save
Limits
Next Previous Incr. Decr. Exit
5. Select Exit.
Save
Limits
Next Previous Incr. Decr.
Exit
6. Select Edit Limits.
Add
Limits
Edit
Limits
Next
Limit
Previous
Limit
Exit
7. Go to Step 3 of Edit Limits (below).
Edit Limits 1. Select Edit Limits.
Add
Limits
Edit
Limits
Next
Limit
Previous
Limit
Exit
The following window is displayed:
2. Enter parameters using the Next, Previous, Incr. and Decr. keys. A coarse
set of values is shown above.
Limit
Options
Save
Limits
Next Previous Incr. Decr.
Exit
Software Version 6 User Manual 8.21
2Di INSPECTION
2Di SETUP
COARSE
20
25
1.00 sq mm
1.50 sq mm
70
65
0.200 mm
0.250 mm
0.015 mm
0.010 mm
80
70
Limit Set ID
BlockageWarning
BlockageAlarm
SmearWarning
SmearAlarm
PasteWarning
PasteAlarm
AlignWarning
AlignAlarm
BridgeWarning
BridgeAlarm
VolumeWarning
VolumeAlarm
Edit Limit Parameters
3. Select Limit Options.
Limit
Options
Save
Limits
Next Previous Incr. Decr. Exit
These are usually set to enabled. If for any reason a particular inspection is not
required, set to disabled. If any global limit set options are disabled the
corresponding parameters are greyed out. These are limit set options, therefore
they are only active for this particular limit set. If a particular inspection is not
required for the whole product, this can be achieved in global limit options,
under edit globals, earlier in this chapter.
If either blockage or paste is set to disabled, volume is also disabled. Once
volume is disabled by this method it is not automatically enabled should both
blockage and paste be re-enabled. Volume must be selected and set to enabled.
4. Enter limit set options using Next, Previous, Incr. and Decr. keys.
Next Previous Incr. Decr.
Exit
5. Select Exit.
Next Previous Incr. Decr.
Exit
6. Select Save Limits.
The message ‘Saving Fiducial Data - Please Wait
Board data file saved’ is displayed.
Limit
Options
Save
Limits
Next Previous Incr. Decr. Exit
7. Select Exit.
Limit
Options
Save
Limits
Next Previous Incr. Decr.
Exit
8. Select Exit.
Add
Limits
Edit
Limits
Next
Limit
Previous
Limit
Exit
8.22 User Manual Software Version 6
2Di INSPECTION
2Di SETUP
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Blockage
Smear
Paste
Alignment
Bridging
Volume
Site Limit Set Options
