3. Select Limit Options . Limit Options Save Limits Next Previous Incr. Decr. Exit These are usually set to enabled. If for any reason a particular inspection is not required, set to disabled. If any global limit set opt…

100%1 / 378
4. Select Save Limits.
The message ‘Saving Fiducial Data - Please Wait
Board data file saved’ is displayed.
Save
Limits
Next Previous Incr. Decr. Exit
5. Select Exit.
Save
Limits
Next Previous Incr. Decr.
Exit
6. Select Edit Limits.
Add
Limits
Edit
Limits
Next
Limit
Previous
Limit
Exit
7. Go to Step 3 of Edit Limits (below).
Edit Limits 1. Select Edit Limits.
Add
Limits
Edit
Limits
Next
Limit
Previous
Limit
Exit
The following window is displayed:
2. Enter parameters using the Next, Previous, Incr. and Decr. keys. A coarse
set of values is shown above.
Limit
Options
Save
Limits
Next Previous Incr. Decr.
Exit
Software Version 6 User Manual 8.21
2Di INSPECTION
2Di SETUP
COARSE
20
25
1.00 sq mm
1.50 sq mm
70
65
0.200 mm
0.250 mm
0.015 mm
0.010 mm
80
70
Limit Set ID
BlockageWarning
BlockageAlarm
SmearWarning
SmearAlarm
PasteWarning
PasteAlarm
AlignWarning
AlignAlarm
BridgeWarning
BridgeAlarm
VolumeWarning
VolumeAlarm
Edit Limit Parameters
3. Select Limit Options.
Limit
Options
Save
Limits
Next Previous Incr. Decr. Exit
These are usually set to enabled. If for any reason a particular inspection is not
required, set to disabled. If any global limit set options are disabled the
corresponding parameters are greyed out. These are limit set options, therefore
they are only active for this particular limit set. If a particular inspection is not
required for the whole product, this can be achieved in global limit options,
under edit globals, earlier in this chapter.
If either blockage or paste is set to disabled, volume is also disabled. Once
volume is disabled by this method it is not automatically enabled should both
blockage and paste be re-enabled. Volume must be selected and set to enabled.
4. Enter limit set options using Next, Previous, Incr. and Decr. keys.
Next Previous Incr. Decr.
Exit
5. Select Exit.
Next Previous Incr. Decr.
Exit
6. Select Save Limits.
The message ‘Saving Fiducial Data - Please Wait
Board data file saved’ is displayed.
Limit
Options
Save
Limits
Next Previous Incr. Decr. Exit
7. Select Exit.
Limit
Options
Save
Limits
Next Previous Incr. Decr.
Exit
8. Select Exit.
Add
Limits
Edit
Limits
Next
Limit
Previous
Limit
Exit
8.22 User Manual Software Version 6
2Di INSPECTION
2Di SETUP
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Blockage
Smear
Paste
Alignment
Bridging
Volume
Site Limit Set Options
Edit Site 1. Select Edit Site. The edit site parameters window is displayed and the site
name parameter is highlighted.
Edit
Global
Edit
Limits
Delete
Site
Next
Site
Previous
Site
Edit
Site
Inspect
Site
Exit
NOTE
Delete site is only available if at least one site exists already. Next site and
previous site are only available if at least two sites exist already.
NOTE
Screen graphic and board graphic are only relevant to GSX/Lt machines.
2. Select Add Site. The cursor flashes along side the site name parameter.
Add
Site
Learn
Site
Light
Setup
Next Previous Incr. Decr. Exit
3. Use the keyboard to enter the site name and press Enter.
NOTE
Site name may be any name up to 20 characters in length including spaces.
Software Version 6 User Manual 8.23
2Di INSPECTION
2Di SETUP
SITE 1
GENERAL
ADVANCED
ADVANCED
X and Y
COARSE
1.00
80.4 mm
86.4 mm
2.00 mm
2.00 mm
WHITE
0.00 mm
0.00 mm
BLACK
0.00 mm
0.00 mm
Edit Site Parameters
SITE NAME
SITE PRIORITY
STENCIL INSPECT TYPE
BOARD INSPECT TYPE
SITE ALIGNMENT
LIMIT SET ID
PASTE SCALING
SITE X COORD
SITE Y COORD
SITE WIDTH
SITE HEIGHT
SCREEN GRAPHIC
SCREEN GRAPHIC X
SCREEN GRAPHIC Y
BOARD GRAPHIC
BOARD GRAPHIC X
BOARD GRAPHIC Y
GENERAL
ADVANCED
ADVANCED
X and Y
COARSE
1.00
80.4 mm
86.4 mm
2.00 mm
2.00 mm
WHITE
0.00 mm
0.00 mm
BLACK
0.00 mm
0.00 mm
Edit Site Parameters
SITE NAME
SITE PRIORITY
STENCIL INSPECT TYPE
BOARD INSPECT TYPE
SITE ALIGNMENT
LIMIT SET ID
PASTE SCALING
SITE X COORD
SITE Y COORD
SITE WIDTH
SITE HEIGHT
SCREEN GRAPHIC
SCREEN GRAPHIC X
SCREEN GRAPHIC Y
BOARD GRAPHIC
BOARD GRAPHIC X
BOARD GRAPHIC Y
