6. Fit the rear squeegee onto the rear squeegee mount, tightening the thumbscrews until they are finger tight. 7. Fit the front squeegee onto the front squeegee mount, ensuring that the thumbscrews are only finger tight.…
The front and rear squeegees must be fitted in the correct positions. Each
squeegee has a keyway machined into it to ensure that it cannot be incorrectly
fitted.
Software Version 6 User Manual 1.11
MACHINE PROGRAMMING
STAGE 4A
NOTE
To prevent incorrect orientation when fitting squeegees, the locking screws on
the rear squeegee are positioned wider apart than those on the front
squeegee. Keyway slots are also in different positions.
Rear Squeegee
Front Squeegee
Rear Squeegee (Front View)
Front Squeegee (Front View)
Squeegee Blade Squeegee Holder
Locking Screw Keyway
Locking Screw
FittoRear
Squeegee Mount
FittoFront
Squeegee Mount
Side View of Squeegee
and Squeegee Mounts
Side View of Squeegee
and Squeegee Mounts
6. Fit the rear squeegee onto the rear squeegee mount, tightening the
thumbscrews until they are finger tight.
7. Fit the front squeegee onto the front squeegee mount, ensuring that the
thumbscrews are only finger tight.
8. Lower the front printhead cover.
9. Press the System button.
10. Select Continue (F1).
Continue
11. If fitted, remove stencil.
1.12 User Manual Software Version 6
MACHINE PROGRAMMING
STAGE 4A
Squeegee Pressure
Height
To complete this calibration, machines with non-feedback pressure system carry
out steps 1-13. For machines with pressure feedback option fitted carry out steps
14 - 17.
Non Feedback 1. Press Calibrat Heights (F2).
Change
Squeegee
Calibrat
Heights
Exit
The message ‘Ensure correct squeegees are fitted!’ is displayed.
2. Press Continue (F1).
Continue
Restore
Defaults
Exit
The message ‘Set Squeegee Pressure Height’ is displayed.
Either:
3. Press Adjust (F2).
Adjust
Save Front
Squeegee
Rear
Squeegee
Step
Up
Step
Down
Exit
The following window is displayed:
4. Using Next, Previous, Incr. and Decr. (F4, F5, F6 and F7) enter the
squeegee heights parameters as necessary.
Next Previous Incr. Decr.
Exit
Software Version 6 User Manual 1.13
MACHINE PROGRAMMING
STAGE 4A
Squeegee Heights Parameters
Front Zero Ref
Rear Zero Ref
4000
4040
