Auto Learn Prior to carrying out auto learn, the 2Di setup described in the preceding pages,

must have been carried out.

1. From the Section Auto Learn, under Module Overview, at the front of this

chapter, identify the position of Site 1 for the required feature.

2. Carry out Section Edit Site for Site 1 coordinates.

3. Carry out Sub Section Lighting Setup, using the same parameters as

previous.

4. Carry out Sub Section Learn Site paras 1-4.

5. Select Auto Learn.

Learn

Board

ReLearn

Screen

Auto

Learn

Next Previous Incr. Decr. Exit

The message ‘Select Component type to Auto Learn:’ is displayed. The

following messages appear beneath this message in rotation:

‘Row - Start at left most end of horizontal’

‘Col - Start at topmost end of vertical’

‘QFP - (Quad Flat Pack) - Start at left most end of top horizontal line’

‘BGA - (Ball Grid Array) - Start at top left corner of array’

‘BGA Frame - Start at top left corner of array frame’

6. Select required component to learn.

Learn

Row

Learn

Column

Learn

QFP

Learn

BGA

Learn

BGA Frame

Abort

The message bar reports the progress of the auto learn as a set of sites of the

appropriate type are created and learnt. The original site, and each site that is

created, is given the same name as the original site, but with a ‘~’ symbol

followed by a three digit number in sequence. While creation and learning is in

progress the following menu bar is displayed:

Abort

Auto Learn

As each new site is created and learnt, the newly created name and data is

displayed in the Edit Site Parameters window.

If Abort Auto Learn is selected the message ‘Site creation and learning

interrupted; do you want to . . . is displayed. The following menu bar is

displayed:

Abandon Continue

If Abandon is selected any sites that have been created are deleted. If Continue is

selected the auto learn resumes, creating and learning sites.

8.34 User Manual Software Version 6

2Di INSPECTION

2Di SETUP

7. On completion of a successful auto learn of the selected component, the

following menu bar is displayed:

Edit

Global

Edit

Limits

Delete

Site

Edit

Site

Inspect

Site

Exit

8. Repeat Steps 1 to 7 for further auto learn features.

9. While creating and learning the sites for a device, if a site is not positioned

correctly for learning, the following menu bar is displayed:

Adjust

Site

Learn

Board

Learn

Screen

Continue Exit

10. Select Adjust Site. The learn site parameters window is displayed.

Adjust

Site

Learn

Board

Learn

Screen

Continue Exit

11. Adjust site parameters as required using Next, Previous, Incr. and Decr.

keys.

Continue Learn

Board

Learn

Screen

Next Previous Incr. Decr.

Exit

12. Select Learn Screen.

Continue Learn

Board

Learn

Screen

Next Previous Incr. Decr. Exit

13. The message ‘Screen Learnt’ is displayed. If the message ‘....Screen Not

Learnt’ is displayed, edit the site parameters and select Learn Screen.

14. Select Learn Board.

Continue

Learn

Board

Learn

Screen

Next Previous Incr. Decr. Exit

15. The message ‘Board Learnt’ is displayed. If the message ‘....Board Not

Learnt’ is displayed, edit the site parameters and select Learn Board.

Software Version 6 User Manual 8.35

2Di INSPECTION

2Di SETUP

SITE X COORD

SITE Y COORD

SITE WIDTH

SITE HEIGHT

SCREEN GRAPHIC X

SCREEN GRAPHIC Y

BOARD GRAPHIC X

BOARD GRAPHIC Y

52.0

36.5

2.00

-0.01

0.00

Learn Site Parameters

16. Select Continue.

Continue

Learn

Board

Learn

Screen

Next Previous Incr. Decr. Exit

17. Select Continue. The auto learn process continues.

Adjust

Site

Learn

Board

Learn

Screen

Continue

Exit

The message bar reports the progress of the auto learn as the system searches for

a site, learns a site and moves to the next site.

18. On completion of a successful auto learn of the selected component, the

following menu bar is displayed:

Edit

Global

Edit

Limits

Delete

Site

Edit

Site

Inspect

Site

Exit

19. Carry out Section Inspect for all sites.
