STAGE 4B ProFlow Setup If squeegees were used when running the last product, carry out the Squeegees to ProFlow Replacement Procedure, see Technical Reference Manual, ProFlow Module Chapter - Replacement Procedures. For …
13. Press Exit (F8)
Mode Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Feedback Option 14. Press Calibrat Heights (F2).
Change
Squeegee
Calibrat
Heights
Exit
The message ‘Ensure correct squeegees are fitted!’ is displayed.
15. Press Continue (F1).
Continue
Restore
Defaults
Exit
The message ‘Calibrating Pressure Heights - DO NOT Open Covers!’ is
displayed.
16. Press Exit (F8).
Continue Restore
Defaults
Exit
17. Press Exit (F8).
Mode Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Software Version 6 User Manual 1.15
MACHINE PROGRAMMING
STAGE 4A
STAGE 4B
ProFlow Setup If squeegees were used when running the last product, carry out the Squeegees to
ProFlow Replacement Procedure, see Technical Reference Manual, ProFlow
Module Chapter - Replacement Procedures.
For setting the contact position, carry out the ProFlow Contact Position Setup,
see Technical Reference Manual, ProFlow Module Chapter - Adjustments and
Settings.
1.16 User Manual Software Version 6
MACHINE PROGRAMMING
STAGE 4B
STAGE 4C
Tooling Setup - FormFlex
CAUTION
BOARD CLAMPS. Care must be taken to ensure that the board clamps
are not damaged when removing or replacing tooling.
1. Select Change Screen (F5).
Mode Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
2. When prompted, open the front printhead cover.
3. If fitted, remove the stencil.
Software Version 6 User Manual 1.17
MACHINE PROGRAMMING
STAGE 4C
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN
WORKING IN THE TOOLING AREA OF THE MACHINE TO AVOID
INJURY. THE FOILS ON THE FRONT AND REAR BOARD CLAMPS
ARE VERY SHARP.
