The following window is displayed: 3. Use the Next and Previous keys (F4 - F5) to highlight the Screen Clean Rate. Save Next Previous Incr. Decr. Exit 4. Use the Incr . and Decr . keys (F6 -F7) to set the Screen Clean Ra…
Clean Screen Modes:
These parameters determine the modes of operation for the screen cleaner. Each
mode can have a cleaning sequence with up to six sweeps, each of which can be
set to VAC, DRY, WET or NONE.
Sweeps set with NONE option cause no action to be taken during the sequence.
For example, the settings:
DRY, NONE, NONE, DRY, NONE, WET and
DRY, DRY, WET, NONE, NONE, NONE
Both carry out two consecutive operations, directly followed by one WET
cleaning operation.
The default setting is NONE for all six steps.
Solvent Advice The following solvents MUST NOT be used in the underscreen cleaner.
However, this list is not complete and does not mean that any solvent not
mentioned is compatible, with DEK machines.
• Rosstech 106 FE
• Rosstech 162 ND
• Acetone
DEK are continuously evaluating alternative solvents. If you require a particular
solvent to be used, but are unsure of its suitability for DEK machines, please
contact the DEK Customer Support Group.
NOTE
Rosstech 147FD is used within DEK manufacturing division and has been found
to be compatible with DEK underscreen cleaner units.
1. Press Setup (F6).
Run Open
Cover
Paste
Load
Clean
Screen
Adjust
Setup
Monitor Maint.
2. Press Edit Data (F3).
Mode Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Software Version 6 User Manual 9.19
CONSUMABLE REPLENISHMENTS
BLUE UNDERSCREEN CLEANER
The following window is displayed:
3. Use the Next and Previous keys (F4 - F5) to highlight the Screen Clean Rate.
Save
Next Previous
Incr. Decr. Exit
4. Use the Incr. and Decr. keys (F6 -F7) to set the Screen Clean Rate. This can
be set at any number between 0 and 200 in increments of 1.
Save Next Previous
Incr. Decr.
Exit
5. Use the Previous key (F5) to highlight the Screen Clean Mode. This
parameter determines the mode of operation of the screen cleaner.
Save Next
Previous
Incr. Decr. Exit
6. Press the Incr. or Decr. keys (F6 - F7) to enter the Screen Clean Mode.
Save Next Previous
Incr. Decr.
Exit
9.20 User Manual Software Version 6
CONSUMABLE REPLENISHMENTS
BLUE UNDERSCREEN CLEANER
The Screen Clean Mode window is opened:
7. Use the Left and Right keys (F2 - F3) to highlight the next sweep number to
be changed.
Left Right
Incr. Decr. Exit
8. Use the Incr. and Decr. keys (F6 - F7) to select the operation required for the
highlighted sweep. The four options are: VAC, DRY, WET and NONE.
Left Right
Incr. Decr.
Exit
9. If the six stage sequence is setup as required, go to the next step, otherwise
return to Step 7.
10. Press Exit (F8).
Left Right Incr. Decr.
Exit
11. Press Exit (F8).
Mode Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Paper and Solvent
Replenishment
Paper and solvent replenishment can take place with the cleaner unit in the
printer. When paper or solvent needs replenishment a warning window is
automatically displayed on the monitor. The warning window varies, depending
on the setting of the consumable action option in set preferences. The message
in the warning window depends on whether the solvent or paper or both require
replenishment. The procedure varies, depending on whether the replenishment
is prior to a print run or during a print run.
Replenishment Prior to a Print Run:
If the set preference is set to warn, continue with Step 1. If the set preference is
set to pause or suspend go to Step 4.
Software Version 6 User Manual 9.21
CONSUMABLE REPLENISHMENTS
BLUE UNDERSCREEN CLEANER
Screen Clean Mode 1
1
WET
2
DRY
3
DRY
4
NONE
5
NONE
6
NONE
Sweep Number
