mayalsoincludenewfeatures thatcomputerprograms(suchastheabovementioned)require

toproperlyinterfacewithStackShot.Thereflashprogramisasimpleapplicationthatletsyou

loadthisnewsoftwareontoyourcontroller.ItalsoinstallsthePCdriversrequiredbythe

stackingprograms.ThisprogramisincludedontheCDshippedwithStackShotandalso

availableonline:

http://www.cognisys‐inc.com/downloads/Reflash.zip





4. Accessories



StackShotisfullycompatiblewithStopShotshuttercables.Awidevarietyofcablesareavailable

athttp://www.cognisys‐inc.com

.

For“nocamerawiresattached”operationyoumightconsidertheuniversalinfraredshutter

trigger.It’scompatiblewithCanon,Nikon,Sony,Pentax,andmanyothercameras.Itsimply

plugsintothe“ShutterTrigger”portofStackShot.Thismayberequiredifyourcameradoesnot

supportawiredshutterrelease.



Figure12‐UniversalIRRemote





35



5. Connections&Cables

OneofthedesigngoalsofStackShotwastomakeitsimpletoaddcableextensionsanddo

customwiring.Nothingismorefrustratingthanbuyingaproductandfindingoutthatituses

over‐pricedproprietarycables.AllStackShotcableextensionsareavailableatyourfavorite

audio/videoequipmentsupplystore.Weprovidetheconnectiondiagramsbelowsothatyou

havetheoptionofmakingcustomcables.Ifyouhaveanyquestions,pleasecontactusat

support@cognisys‐inc.com

.



5.1 ShutterTriggerOutput

Thetriggeroutputusesastandard“RCA”jack.RCAexte nsionscomeinalldifferenttypes,one

endasmaleandtheotherasfemale.Toextendtheshuttertriggercable length,simplybuya

mono(single)extensionwhichistypicallyusedforvideo.



AswithallRCAjackstheoutsideconnectorisground.TheStackShottriggeroutputisa“Low

SideDriver”(switchesinground).Thismeansthatwhentheshuttertriggeroutputfires,it

connectsthecenterconductoroftheRCAjacktotheoutsideconnector(ground)todraw

currentthroughthecenterconductor.



SeeFigure13belowforawiringdiagramfortheRCAconnectors.



Figure13‐RCAconnector



5.2 MotorCable

Themotorcableincludedwiththekitisahigh‐qualityS‐video/SVHScablewithlowimpedance.

IfyouaregoingtoextendthelengthbetweentheStackShotcontrollerandtherailmakesureto

useahigh‐qualitycable–otherwiseperformancemaybesacrificed.







36


