5. Connections&Cables

OneofthedesigngoalsofStackShotwastomakeitsimpletoaddcableextensionsanddo

customwiring.Nothingismorefrustratingthanbuyingaproductandfindingoutthatituses

over‐pricedproprietarycables.AllStackShotcableextensionsareavailableatyourfavorite

audio/videoequipmentsupplystore.Weprovidetheconnectiondiagramsbelowsothatyou

havetheoptionofmakingcustomcables.Ifyouhaveanyquestions,pleasecontactusat

support@cognisys‐inc.com

.



5.1 ShutterTriggerOutput

Thetriggeroutputusesastandard“RCA”jack.RCAexte nsionscomeinalldifferenttypes,one

endasmaleandtheotherasfemale.Toextendtheshuttertriggercable length,simplybuya

mono(single)extensionwhichistypicallyusedforvideo.



AswithallRCAjackstheoutsideconnectorisground.TheStackShottriggeroutputisa“Low

SideDriver”(switchesinground).Thismeansthatwhentheshuttertriggeroutputfires,it

connectsthecenterconductoroftheRCAjacktotheoutsideconnector(ground)todraw

currentthroughthecenterconductor.



SeeFigure13belowforawiringdiagramfortheRCAconnectors.



Figure13‐RCAconnector



5.2 MotorCable

Themotorcableincludedwiththekitisahigh‐qualityS‐video/SVHScablewithlowimpedance.

IfyouaregoingtoextendthelengthbetweentheStackShotcontrollerandtherailmakesureto

useahigh‐qualitycable–otherwiseperformancemaybesacrificed.







36



37



6. Setupexamples

6.1 MirrorLockup



Mirrorlock‐upisacommonlyusedfeatureinmacrophotographytoreducevibrationofthe

cameraduringshooting.SLRcamerasswingthemirrorupoutofthelight‐pathtothefilmor

sensorjustpriortotheshutteropening.Thismovementultimatelyleadstovibrationwhichcan

inducemotionblurinthepicture.Somecamerashavetheabilitytoenableafeaturewherethe

firstbuttonpressoftheshutterswingsthemirrorupandthesecondbuttonpressopensthe

shutter.ThisfeaturecanbeprogrammedintoStackShotbygoingintotheconfigurationmenu.



ThismethodisidenticaltosettingStackShottotakemultiplepictures.PresstheCONFIGbutton

toentertheglobalconfiguration:



== Global Config ==

> # pics: 1

Tsettle: 500.0 ms

Toff: 500.0 ms ->



Withthecursornextto“#pics”(discussedinsection3.3.1),presstheUPbuttontochangethe

settingto“2”.Thiswillcausetheshutteroutputtofiretwotimespercamerastep.Thefirst

timewillswingthemirrorupandthesecondwillexposetheimage.We’renotquiteyetdone

though.PresstheSELECTbuttonuntilthecursorisnextto“Toff”.



== Global Config ==

# pics: 1

Tsettle: 500.0 ms

> Toff: 500.0 ms ->



“Toff”isthetimetheshutteroutputwillremainoffbetweenoutputpulses(seesection3.3.3for

moredetails).Inthiscase,thiswillbethetimebetweenwhenthemirrorisraisedandthe

pictureisactuallytaken.AdjustthisparameterusingtheUP/DOWNbuttonstoasuitablevalue

toletthemirrorvibrationsettleoutprior toexposingtheimage.PresstheCONFIGbuttononce

moreanditwillreturnyoutothemainmenu.



6.2 100mmvs.TheOrchid

InthissetupexamplewehaveaCanon7D,EF100mmmacrolens,andofcourseStackShot.



Figure14‐StackShotOrchidSetup

TheStackShotcontrollercoordinatesthecameraposition,settlingtime,exposure(and

potentiallyexposurebracketing),andautomati creturnuponcompletion.Theoptionalauto‐

returnfeatureallowsadjustmentofthecamera’sparametersandlightingwitho uthavingtore‐

positionthecamera.

FortheOrchiditwasdecidedthat“AutoStep”mode beused(seesection3.7formoredetails).

“#Steps”wasadjustedto10steps(11pictures)which wouldresultinanoutstan dingfinal

stackedimage.

Mode: Auto-Step

> # Steps: 10

Select Start Pos



TheFWDbuttonwaspresseduntilthecamerareachedthedesiredstartingpointofthestack.

Picktheclosestobjectyouwantinfocusforthestackandmovethecamerasuchthatthisisin

sharpfocus.TheSELECTbuttonwasthenpressedtoacknowle dgethestartingposition.Then

theBACKbuttonwaspressedtomovethecameratotheendpointofthestack.Movethe

cameratothepointwherethefurthestawayelementinyourcompositionisinfocus.Againthe

SELECTbuttonwaspressedtoconfirmthefinalposition.Thedisplaythenshowedthe

following:


